Hubbell
HBL1221PL HUB 20A SP RED PL SW..

Mouse over image to zoom, click to enlarge

  • HBL1221PL HUB 20A SP RED PL SW..
  • HBL1221PL HUB 20A SP RED PL SW..
  • HBL1221PL HUB 20A SP RED PL SW..
  • HBL1221PL HUB 20A SP RED PL SW..
  • HBL1221PL HUB 20A SP RED PL SW..

Description: Hubbell Wiring Device-Kellems HBL®, HBL1221PL, Toggle Switch, Extra Heavy Duty General Purpose Pilot Light Standard, Series: HBL®, 120 to 277 V AC, 20 A, 5540 W Power, 2-Position Contact Configuration, 1 Pole, Toggle Actuator, Threaded Mounting, Back/Side Wire Terminal, 50000 cycles Operating Cycles, Thermoset, Red, Environmental Conditions: -40 to 75 deg C, 4.06 x 1.31 x 1.86 in Dimensions

Manufacturer PN: HBL1221PL

UPC:  78358543146

Kendall Electric Inc PN: 32308

Invoice Description:

HBL1221PL HUB 20A SP RED PL SW..


SPEC SHEET

▸ See All in Toggle Switches


How Can We Make This Page Better?

Hubbell Wiring Device-Kellems HBL® HBL1221PL HBL® Extra Heavy Duty General Purpose Pilot Light Standard Toggle Switch, 120 to 277 V AC, 20 A, 5540 W Power Rating, 2-Position Contact

Log In for Pricing and Availability




Description

Hubbell Wiring Device-Kellems HBL®, HBL1221PL, Toggle Switch, Extra Heavy Duty General Purpose Pilot Light Standard, Series: HBL®, 120 to 277 V AC, 20 A, 5540 W Power, 2-Position Contact Configuration, 1 Pole, Toggle Actuator, Threaded Mounting, Back/Side Wire Terminal, 50000 cycles Operating Cycles, Thermoset, Red, Environmental Conditions: -40 to 75 deg C, 4.06 x 1.31 x 1.86 in Dimensions

Specifications

 Actuator Toggle
 Amperage Rating 20 A
 Application Industrial Applications and Indoor Dry Environment
 Brand Name Hubbell Premise Wiring
 Color Red
 Contact Configuration 2-Position
 Dimensions 4.06 x 1.31 x 1.86 in
 Environmental Conditions -40 to 75 deg C
 Manufacturer Part Number HBL1221PL
 Material Thermoset
 Mounting Threaded
 Number of Poles 1
 Operating Cycles 50000 Cycles
 PART NUMBER KEYWORDS HBL1221PL ; 1221PL ; 11830676 ; 8942788 ; 783585431468 ; 78358543146 ; 00783585431468 ; 0783585431468
 Power Rating 5540 W
 Series HBL®
 Standards/Approvals NEMA WD1|CSA Certified|UL94 V-2 Flammability Rating|UL 20|Federal Specification W-S-896
 Terminal Type Back/Side Wire
 Type Extra Heavy Duty General Purpose Pilot Light Standard
 Video Links
 Voltage Rating 120 to 277 V AC

Features

▪ Strip gauge for accurate wiring
▪ Abuse resistant nylon toggle
▪ Large brass binding head screws with deep slots
