Hubbell
GFSPST15W HUBBELL 15A COM SELF TEST COMB SWITCH, TR GFR WH 88377812462

Mouse over image to zoom, click to enlarge

  • GFSPST15W HUBBELL 15A COM SELF TEST COMB SWITCH, TR GFR WH 88377812462
  • GFSPST15W HUBBELL 15A COM SELF TEST COMB SWITCH, TR GFR WH 88377812462
  • GFSPST15W HUBBELL 15A COM SELF TEST COMB SWITCH, TR GFR WH 88377812462
  • GFSPST15W HUBBELL 15A COM SELF TEST COMB SWITCH, TR GFR WH 88377812462
  • GFSPST15W HUBBELL 15A COM SELF TEST COMB SWITCH, TR GFR WH 88377812462

Description: Wiring Device-Kellems AUTOGUARD® GFCI Receptacle, 1-Phase Auto Grounding Duplex Heavy Duty Self-Test Tamper Resistant Standard Screw Mount, 125 VAC, 15 A, 1/2 hp, 60 Hz Frequency, 2 Pole, 3 Wires, 5-15R NEMA Rating, Commercial Grade, -40 to 75 deg C, Screw Terminal, Composite, White, 1.75 in W x 1.47 in D x 3.28 in H

Manufacturer PN: GFSPST15W

UPC:  88377812462

Kendall Electric Inc PN: 3564527

Invoice Description:

GFSPST15W HUBBELL 15A COM SELF TEST COMB SWITCH, TR GFR WH 88377812462


SPEC SHEET

▸ See All in Combination GFCI Devices


How Can We Make This Page Better?

Wiring Device-Kellems AUTOGUARD® GFSPST15W 1-Phase Auto Grounding Duplex Heavy Duty Self-Test Tamper Resistant Standard Screw Mount GFCI Receptacle With 1-Pole Combination Switch, 125 VAC, 15 A, 2 Poles, 3 Wires, White

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Hubbell® AUTOGUARD® GFCI receptacles continually test and monitor for "people protection capability" automatically. This patented safety feature includes disconnecting power to the receptacle if critical components are damaged and GFCI protection is lost. GFCI auto-monitoring is conducted continuously within every 30 sec. Also, clear visual indicators are provided on the device face representing power status, trip condition, ground fault condition and end of life status. In addition, for added safety, power will be denied to the receptacle face if reverse wiring of line and load was to occur.
Wiring Device-Kellems AUTOGUARD® GFCI Receptacle, 1-Phase Auto Grounding Duplex Heavy Duty Self-Test Tamper Resistant Standard Screw Mount, 125 VAC, 15 A, 1/2 hp, 60 Hz Frequency, 2 Pole, 3 Wires, 5-15R NEMA Rating, Commercial Grade, -40 to 75 deg C, Screw Terminal, Composite, White, 1.75 in W x 1.47 in D x 3.28 in H

Specifications

 Amperage Rating 15 A
 Application Power Protection and Indoor Dry Environment Applications
 Brand Name Hubbell Premise Wiring
 Color White
 Dimensions 1.75 in W x 1.47 in D x 3.28 in H
 Frequency Rating 60 Hz
 Grade Commercial
 Horsepower 2-Jan hp
 Includes Multiple Drive Screw
 Manufacturer Part Number GFSPST15W
 Material Composite
 NEMA Rating 5-15R
 Number of Poles 2
 Number of Wires 3
 Standards/Approvals RoHS Compliant|UL 943 Class A|UL 498|UL File No. E41978|CSA Certified|NEC Certified|CEC Approved|NEMA WD6|ANSI 73
 Temperature Rating -40 to 75 deg C
 Terminal Type Screw
 Type 1-Phase Auto Grounding Duplex Heavy Duty Self-Test Tamper Resistant Standard Screw Mount
 Video Links
 Voltage Rating 125 VAC

Features

▪ Patented AUTOGUARD® self test technology
▪ Triple wipe construction
▪ Patented shutter design for tamper-resistant
