GENERAL ELECTRIC TQ2130 2P 30A 240V CIRCUIT BREAKER SQUARE D REPLACEMNT

Mouse over image to zoom, click to enlarge

  • GENERAL ELECTRIC TQ2130 2P 30A 240V CIRCUIT BREAKER SQUARE D REPLACEMNT
  • GENERAL ELECTRIC TQ2130 2P 30A 240V CIRCUIT BREAKER SQUARE D REPLACEMNT
  • GENERAL ELECTRIC TQ2130 2P 30A 240V CIRCUIT BREAKER SQUARE D REPLACEMNT

Description: GE Special Purpose Circuit Breaker, Type TQ, 240 V AC, 30 A, 50/60 Hz, 10 kA Interrupt, Q-Line Frame, Thermal Magnetic Trip, 2 Pole, 1 ph, Pivot/Toggle Handle Actuator, Load Lug, Box Terminal, Plug-In Mount, 10 to 50 deg C, 1-1/2 in W x 2-3/8 in D x 3 in H, Plastic

Manufacturer PN: TQ2130

UPC:  78316408390

Kendall Electric Inc PN: 4364360

Invoice Description:

GENERAL ELECTRIC TQ2130 2P 30A 240V CIRCUIT BREAKER SQUARE D REPLACEMNT


SPEC SHEET

How Can We Make This Page Better?

GE TQ2130 Type TQ Special Purpose Circuit Breaker, 240 V AC, 30 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

GE Special Purpose Circuit Breaker, Type TQ, 240 V AC, 30 A, 50/60 Hz, 10 kA Interrupt, Q-Line Frame, Thermal Magnetic Trip, 2 Pole, 1 ph, Pivot/Toggle Handle Actuator, Load Lug, Box Terminal, Plug-In Mount, 10 to 50 deg C, 1-1/2 in W x 2-3/8 in D x 3 in H, Plastic

Specifications

 Actuator Type Pivot/Toggle Handle
 Amperage Rating 30 A
 Application Square D™ QO Load Centers, Electrical Distribution and Control Applications
 Brand Name GE
 Connection Type Load Lug
 Dimensions 1-1/2 in W x 2-3/8 in D x 3 in H
 Frame Q-Line
 Frequency Rating 50/60 Hz
 Manufacturer Part Number TQ2130
 Material Plastic
 Mounting Type Plug-In
 Number of Poles 2
 PART NUMBER KEYWORDS TQ2130 ; 7676363 ; 783164083903 ; 78316408390 ; 00783164083903
 Phase 1
 Standards/Approvals ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL File No. E11592
 Temperature Rating 10 to 50 deg C
 Terminal Type Box
 Type Type TQ
 Voltage Rating 240 V AC

Features

▪ 60 deg C/75 deg F conductor rating
▪ Quick-make and quick-break operating mechanism
▪ Multi-pole breakers incorporate internal common trip
▪ 3/4 in UL classified circuit breakers

Resources

 Catalog Page
 Product Data Sheet
