Description: GE Mod™ III Modular Metering Main Lug Module, 4-Wire, 120/208Y/240 V AC, 400 A, 3 ph, Bottom/Top Feed, NEMA 3R Enclosure, 6 AWG to 600 kcmil, 1/0 AWG to 250 kcmil Wire, 100 kA Short Circuit, Center/End Mounting, 48.7 in H x 13.5 in W x 7 in D Dimensions

Manufacturer PN: TMP3L4R

UPC:  78316419419

Kendall Electric Inc PN: 2560053

Invoice Description:

GE TMP3L4R 400A MAIN LUG MODULE


SPEC SHEET

▸ See All in Main Lug Terminal Box Modules


How Can We Make This Page Better?

GE Mod™ III TMP3L4R 4-Wire Modular Metering Main Lug Module, 120/208Y/240 V AC, 400 A, 3 Phase, Bottom/Top Feed, NEMA 3R Enclosure

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

GE Mod™ III Modular Metering Main Lug Module, 4-Wire, 120/208Y/240 V AC, 400 A, 3 ph, Bottom/Top Feed, NEMA 3R Enclosure, 6 AWG to 600 kcmil, 1/0 AWG to 250 kcmil Wire, 100 kA Short Circuit, Center/End Mounting, 48.7 in H x 13.5 in W x 7 in D Dimensions

Specifications

 Amperage Rating 400 A
 Application Industrial, Commercial, Electrical Distribution and Control Applications
 Brand Name GE
 Dimensions 48.7 in H x 13.5 in W x 7 in D
 Enclosure NEMA 3R
 Feed Type Bottom/Top
 Includes Mounting Lugs
 Manufacturer Part Number TMP3L4R
 Mounting Type Center/End
 PART NUMBER KEYWORDS TMP3L4R ; 7695363 ; 783164194197 ; 78316419419 ; 00783164194197
 Phase 3
 Short Circuit Current Rating 100 kA
 Type 4-Wire
 Voltage Rating 120/208Y/240 V AC

Features

▪ 100 kA interrupt rating

Resources

 Catalog Page
 Product Data Sheet
