Eaton
FNA-20 BUS IND FUSE (1)

Mouse over image to zoom, click to enlarge

  • FNA-20 BUS IND FUSE (1)
  • FNA-20 BUS IND FUSE (1)
  • FNA-20 BUS IND FUSE (1)
  • FNA-20 BUS IND FUSE (1)
  • FNA-20 BUS IND FUSE (1)

Description: Bussmann Midget Fuse, Pin Indicating Time Delay, Series: FNA, Indicating/Non-Indicating: Indicating, Rejection/Non-Rejection: Non-Rejection, 20 A, 32 VAC, 1000 A Interrupt, Class: Supplemental, Ferrule Terminal, Holder Mount, Cartridge Body Type, Dual Element, Fiberglass, Gray, 13/32 in Dia x 1-1/2 in L Body Size

Manufacturer PN: FNA-20

UPC:  05171271367

Kendall Electric Inc PN: 21522

Invoice Description:

FNA-20 BUS IND FUSE (1)


SPEC SHEET

▸ See All in Midget Fuses


How Can We Make This Page Better?

Bussmann FNA-20 Pin Indicating Time Delay Midget Fuse, 20 A, 32 VAC, 1000 A Interrupt, Class: Supplemental, Cartridge Body

Log In for Pricing and Availability




Description

Bussmann offers an extensive line of Supplemental and Midget Fuses to meet your circuit protection needs. Supporting this offering is an equally broad offering of Compact Fuseholders, blocks, terminal blocks and disconnects.
Bussmann Midget Fuse, Pin Indicating Time Delay, Series: FNA, Indicating/Non-Indicating: Indicating, Rejection/Non-Rejection: Non-Rejection, 20 A, 32 VAC, 1000 A Interrupt, Class: Supplemental, Ferrule Terminal, Holder Mount, Cartridge Body Type, Dual Element, Fiberglass, Gray, 13/32 in Dia x 1-1/2 in L Body Size

Specifications

 Amperage Rating 20 A
 Application Power Electronic Circuits with High In-Rush Current Applications, Safety and Security Systems
 Body Size 13/32 in Dia x 1-1/2 in L
 Body Type Cartridge
 Brand Name Bussmann
 Class Supplemental
 Color Gray
 Element Dual
 Indicating Non Indicating Indicating
 Manufacturer Part Number FNA-20
 Material Fiberglass
 Mounting Type Holder
 Rejection Non Rejection Non-Rejection
 Series FNA
 Standards/Approvals CE Certified|CSA 1422-01|CSA File No. 53787|RoHS Compliant|UL File No. E19180
 Terminal Type Ferrule
 Type Pin Indicating Time Delay
 Video Links
 Voltage Rating 32 VAC

Features

▪ Pin indication for visual indication of open fuse condition
▪ Dual element, time delay performance permits close sizing on control transformers and relays
▪ Silver plated pin for positive, electrical signal activation
