| ▪ Power: IEEE 1459 |
| ▪ Tamper protection: Kensington lock slot |
| ▪ Harmonics: IEC 61000 to 4-7: Class 1 |
| ▪ Resolution: 16-bit synchronous sampling |
| ▪ Relative humidity, operating: 15% to 85% non-condensing |
| ▪ On-battery runtime: Four Hours in standard operating mode, upto 5.5 Hours in power saving mode |
| ▪ Accuracy: /- 1% |
| ▪ Operating altitude: 2000 m (up to 4000 m derate to 1000 V CAT II/600 V CAT III/300 V CAT IV) |
| ▪ Input voltage: Clamp input: 500 mVrms/50 mVrms; CF 2.8 |
| ▪ Coupling material: POM ABS/PC |
| ▪ Triggered recordings: Full cycle RMS updated every half cycle of voltage and current (Urms1/2 according to IEC61000 to 4-30) |
| ▪ Total harmonic distortion: Calculated on 50 harmonics |
| ▪ Temperature coefficient over operating temperature range: 0.05% of reading/ Degrees C 0.09% of reading/ Degrees F |
| ▪ Enclosure: IP50 in accordance with EN60529 |
| ▪ Averaging interval: 10 Minutes |
| ▪ Mains power frequency: 50/60 Hz /-15% |
| ▪ Input signal frequency: 50/60 Hz (42.5 to 69 Hz) |
| ▪ Probe cable length: 305 mm (12 in) |
| ▪ Maximum no-load consumption: < .3 W only when powered using IEC 60320 input |
