Eaton
FAZ-D10/1-SP CH FAZ UL 1077 SUPPLEMENTARY 1P 10A D CURVE SINGLE PKG

Mouse over image to zoom, click to enlarge

  • FAZ-D10/1-SP CH FAZ UL 1077 SUPPLEMENTARY 1P 10A D CURVE SINGLE PKG
  • FAZ-D10/1-SP CH FAZ UL 1077 SUPPLEMENTARY 1P 10A D CURVE SINGLE PKG
  • FAZ-D10/1-SP CH FAZ UL 1077 SUPPLEMENTARY 1P 10A D CURVE SINGLE PKG

Description: EATON Supplementary Protector, Standard Current Limiting, Series: FAZ, 277 VAC, 48 VDC, 10 A, 10 kA Interrupt, Thermal Magnetic Trip, 1 Pole, Handle Actuator, 18 to 4 AWG, 18 to 8 AWG Wire, IP20 Enclosure, DIN Rail Mounting, -40 to 75 deg C, 0.69 in L Dimensions, Nylon

Manufacturer PN: FAZ-D10/1-SP

UPC:  01508163688

Kendall Electric Inc PN: 3523260

Invoice Description:

FAZ-D10/1-SP CH FAZ UL 1077 SUPPLEMENTARY 1P 10A D CURVE SINGLE PKG


SPEC SHEET

How Can We Make This Page Better?

EATON FAZ-D10/1-SP Standard Current Limiting Supplementary Protector, 277 VAC, 48 VDC, 10 A, 10 kA Interrupt, 1 Poles, Thermal Magnetic Trip

Log In for Pricing and Availability




Description

Eaton's FAZ, dual rated UL and IEC circuit breakers are ideal for providing protection in many applications. A current limiting design provides fast short-circuit interruption, offering superior protection by reducing peak let-through current. Superior product quality, tested reliability and safety make Eaton’s UL 1053 Residual Current Circuit Breaker (RCCB) the optimum product for residual current applications. The UL 1053 RCCB circuit breakers provide safety and protection for personnel and equipment.
EATON Supplementary Protector, Standard Current Limiting, Series: FAZ, 277 VAC, 48 VDC, 10 A, 10 kA Interrupt, Thermal Magnetic Trip, 1 Pole, Handle Actuator, 18 to 4 AWG, 18 to 8 AWG Wire, IP20 Enclosure, DIN Rail Mounting, -40 to 75 deg C, 0.69 in L Dimensions, Nylon

Specifications

 Actuator Type Handle
 Amperage Rating 10 A
 Application Circuit Protection, Control Circuits, Lighting, Business Equipment, Appliances, Conventional Energy, Renewable Energy and Alternative Energy Generation, Datacenters, IT Space - CI, Hyper Converged, Marine Vessels and Equipment and Industrial Applications
 Brand Name EATON
 Dimensions 0.69 in L
 Enclosure IP20
 Manufacturer Part Number FAZ-D10/1-SP
 Material Nylon
 Mounting Type DIN Rail
 Number of Poles 1
 PART NUMBER KEYWORDS FAZ-D10/1-SP ; FAZD101SP ; 11719613 ; 04015081636884 ; 4015081636884
 Series FAZ
 Standards/Approvals IEC 60947-2,UL 1077,CSA Std. C22.2 No.235
 Temperature Rating -40 to 75 deg C
 Type Standard Current Limiting
 Voltage Rating 277 V AC/48 V DC

Features

▪ Suitable for applications where high levels of inrush current are expected
▪ Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
▪ Thermal magnetic over current protection
▪ Trip-free design breaker can not be defeated by holding the handle in the On position
▪ A color coded red/green indicator provides immediate visual indication of device status (green for Off, red for On) and isolation function
▪ Power to the circuit breakers can be fed from the line or load side
▪ Captive screws cannot be lost
▪ Small modular width of the device and accessories saves space in the panel or equipment, which can lead to cost savings
▪ D-curve designed for highly inductive loads
▪ For international and domestic use
