Eaton
FAZ-C20/1-NA-SP CH FAZ-NA UL 489 MCB 1P 20A C CURVE SINGLE PKG

Mouse over image to zoom, click to enlarge

  • FAZ-C20/1-NA-SP CH FAZ-NA UL 489 MCB 1P 20A C CURVE SINGLE PKG
  • FAZ-C20/1-NA-SP CH FAZ-NA UL 489 MCB 1P 20A C CURVE SINGLE PKG
  • FAZ-C20/1-NA-SP CH FAZ-NA UL 489 MCB 1P 20A C CURVE SINGLE PKG
  • FAZ-C20/1-NA-SP CH FAZ-NA UL 489 MCB 1P 20A C CURVE SINGLE PKG

Description: EATON Supplementary Protector, Current Limiting, Series: FAZ, 277/480 V AC, 20 A, 50/60 Hz Frequency, 10 to 14 kA Interrupt, Thermal Magnetic Trip, 1 Pole, Lever/Toggle Actuator, 18 to 6 AWG Wire, IP20 Enclosure, DIN Rail Mounting, -40 to 75 deg C, 0.7 x 2.75 x 4.13 in Dimensions, Nylon

Manufacturer PN: FAZ-C20/1-NA-SP

UPC:  01508163636

Kendall Electric Inc PN: 3406841

Invoice Description:

FAZ-C20/1-NA-SP CH FAZ-NA UL 489 MCB 1P 20A C CURVE SINGLE PKG


SPEC SHEET

▸ See All in Miniature Circuit Breakers


How Can We Make This Page Better?

EATON FAZ-C20/1-NA-SP Current Limiting Supplementary Protector, 277/480 V AC, 20 A, 10 to 14 kA Interrupt, 1 Poles, Thermal Magnetic Trip

Log In for Pricing and Availability




Description

Eaton's FAZ, dual rated UL and IEC circuit breakers are ideal for providing protection in many applications. A current limiting design provides fast short-circuit interruption, offering superior protection by reducing peak let-through current. Superior product quality, tested reliability and safety make Eaton’s UL 1053 Residual Current Circuit Breaker (RCCB) the optimum product for residual current applications. The UL 1053 RCCB circuit breakers provide safety and protection for personnel and equipment.
EATON Supplementary Protector, Current Limiting, Series: FAZ, 277/480 V AC, 20 A, 50/60 Hz Frequency, 10 to 14 kA Interrupt, Thermal Magnetic Trip, 1 Pole, Lever/Toggle Actuator, 18 to 6 AWG Wire, IP20 Enclosure, DIN Rail Mounting, -40 to 75 deg C, 0.7 x 2.75 x 4.13 in Dimensions, Nylon

Specifications

 Actuator Type Lever/Toggle
 Amperage Rating 20 A
 Application Convenience Receptacle Circuits, Motor Control Circuits, Load Circuits Leaving the Equipment, HACR Equipment, PLC I/O Points, Computers, Power Supplies, Control Instrumentation, Relays, UPS, Power Conditioners, Conventional Energy, Renewable Energy and Alternative Energy Generation, Datacenters, IT Space - CI, Hyper Converged, Marine Vessels and Equipment and Industrial Applications
 Brand Name EATON
 Dimensions 0.7 x 2.75 x 4.13 in
 Enclosure IP20
 Frequency Rating 50/60 Hz
 Manufacturer Part Number FAZ-C20/1-NA-SP
 Material Nylon
 Mounting Type DIN Rail
 Number of Poles 1
 PART NUMBER KEYWORDS FAZ-C20/1-NA-SP ; FAZC201NASP ; 11719527 ; 04015081636365 ; 4015081636365
 Series FAZ
 Standards/Approvals UL 489,CSA Std. C22.2 No. 235
 Temperature Rating -40 to 75 deg C
 Type Current Limiting
 Voltage Rating 277/480 V AC

Features

▪ Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
▪ Trip-free design breaker can not be defeated by holding the handle in the On position
▪ A color coded red/green indicator provides immediate visual indication of device status (green for Off, red for On) and isolation function
▪ Power to the circuit breakers can be fed from the line or load side
▪ Captive screws cannot be lost
▪ To save installation time, bus connectors and feeder terminal facilitate mounting and wiring of multiple miniature circuit breaker arrays in control panel assemblies
▪ SWD (switching duty) suitable for switching fluorescent lighting loads
▪ C curve devices are suitable for applications where medium levels of inrush current are expected
▪ C curve devices provide a medium magnetic trip point
