Eaton
ER4X-40N3PB BUSSMANN ENCLOSED DISCONNECTS

Mouse over image to zoom, click to enlarge

  • ER4X-40N3PB BUSSMANN ENCLOSED DISCONNECTS
  • ER4X-40N3PB BUSSMANN ENCLOSED DISCONNECTS
  • ER4X-40N3PB BUSSMANN ENCLOSED DISCONNECTS
  • ER4X-40N3PB BUSSMANN ENCLOSED DISCONNECTS

Description: Bussmann Enclosed Rotary Disconnect Switch, Non-Fused, Series: ER, 600 V AC, 40 A, 25 hp, 3 Pole, 65 kA/30 A to 10 kA/60 A Short Circuit Current Rating, Black Pistol Handle Actuator, NEMA 4X, -20 to 70 deg C, 6 in W x 6 in D x 8 in H, 304 Stainless Steel

Manufacturer PN: ER4X-40N3PB

UPC:  05171248778

Kendall Electric Inc PN: 3950975

Invoice Description:

ER4X-40N3PB BUSSMANN ENCLOSED DISCONNECTS


SPEC SHEET

▸ See All in Enclosed Rotary Disconnects


How Can We Make This Page Better?

Bussmann ER4X-40N3PB Non-Fused Enclosed Rotary Disconnect Switch, 600 V AC, 40 A, 25 hp, 3 Poles

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Bussmann Enclosed Rotary Disconnect Switch, Non-Fused, Series: ER, 600 V AC, 40 A, 25 hp, 3 Pole, 65 kA/30 A to 10 kA/60 A Short Circuit Current Rating, Black Pistol Handle Actuator, NEMA 4X, -20 to 70 deg C, 6 in W x 6 in D x 8 in H, 304 Stainless Steel

Specifications

 Actuator Type Black Pistol Handle
 Amperage Rating 40 A
 Application Motor Disconnect, Stationary Machine Equipment in Factory and Robotics Applications
 Brand Name Bussmann
 Dimensions 6 in W x 6 in D x 8 in H
 Enclosure NEMA 4X
 Horsepower 25 hp
 Manufacturer Part Number ER4X-40N3PB
 Material 304 Stainless Steel
 Number of Poles 3
 PART NUMBER KEYWORDS ER4X-40N3PB ; ER4X40N3PB ; 12260883 ; 051712487788 ; 51712487788 ; 05171248778 ; 00051712487788
 Series ER
 Short Circuit Current Rating 65 kA/30 A to 10 kA/60 A
 Standards/Approvals CE Marked
 Temperature Rating -20 to 70 deg C
 Type Non-Fused
 Video Links
 Voltage Rating 600 V AC

Features

▪ Multiple field installed accessories enhance the enclosed disconnect switches to fit the desired application
▪ Lockout/tagout up to three 1/4 in shank padlocks can be installed on external handles

Resources

 Catalog Page
 Product Data Sheet
