Intermatic
EK4235S I-MATIC STEM SWIVEL MOUNT ELECTRONIC PHOTOCONTROL, 480 V

Mouse over image to zoom, click to enlarge

  • EK4235S I-MATIC STEM SWIVEL MOUNT ELECTRONIC PHOTOCONTROL, 480 V
  • EK4235S I-MATIC STEM SWIVEL MOUNT ELECTRONIC PHOTOCONTROL, 480 V
  • EK4235S I-MATIC STEM SWIVEL MOUNT ELECTRONIC PHOTOCONTROL, 480 V
  • EK4235S I-MATIC STEM SWIVEL MOUNT ELECTRONIC PHOTOCONTROL, 480 V

Description: Intermatic® NightFox™ Electronic Photocontrol, Swivel, Series: EK4000 Series, LED Fixture, 480 V AC, 5000 A, 50/60 Hz Frequency, 1000 W Tungsten, 0.35 A Ballast, 2 to 5 s Timing, 18 AWG Wire, Solid State Photo/Silicon IR Filtered Sensor, 1.5 FC Turn ON/4.5 FC Turn OFF Sensitivity, Environmental Conditions: -40 to 158 deg F, 10000 hr Operating Cycles, Box/Fixture Mounting, Polycarbonate, Gray, 1-5/16 in W x 1-1/4 in D x 5-5/8 in H Dimensions

Manufacturer PN: EK4235S

UPC:  07827515241

Kendall Electric Inc PN: 4329249

Invoice Description:

EK4235S I-MATIC STEM SWIVEL MOUNT ELECTRONIC PHOTOCONTROL, 480 V


SPEC SHEET

▸ See All in Stem & Swivel Mounting Photocontrols


How Can We Make This Page Better?

Intermatic® NightFox™ EK4235S Swivel Electronic Photocontrol, 480 V AC, 1000 W Tungsten, 0.35 A Ballast, Box/Fixture Mount, Polycarbonate

Log In for Pricing and Availability




Description

NIGHTFOX electronic photocontrols permanently install on outdoor electrical boxes or outdoor lighting fixtures. Ideal for LED fixtures with long-life expectations. ½”-14 NPSM threaded stem fits standard outlet boxes and wall packs with a minimum installation hole size of 7/8” diameter. Come with 9" wire leads.
Intermatic® NightFox™ Electronic Photocontrol, Swivel, Series: EK4000 Series, LED Fixture, 480 V AC, 5000 A, 50/60 Hz Frequency, 1000 W Tungsten, 0.35 A Ballast, 2 to 5 s Timing, 18 AWG Wire, Solid State Photo/Silicon IR Filtered Sensor, 1.5 FC Turn ON/4.5 FC Turn OFF Sensitivity, Environmental Conditions: -40 to 158 deg F, 10000 hr Operating Cycles, Box/Fixture Mounting, Polycarbonate, Gray, 1-5/16 in W x 1-1/4 in D x 5-5/8 in H Dimensions

Specifications

 Amperage Rating 5000 A
 Application Exterior Lighting, Landscape Lighting, Parking Lot Lighting, Pedestrian Pathway, Street Lighting and Outdoor Lighting Control Applications
 Ballast Load 0.35 A
 Brand Name Intermatic®
 Color Gray
 Dimensions 1-5/16 in W x 1-1/4 in D x 5-5/8 in H
 Environmental Conditions -40 to 158 deg F
 Fixture Type LED
 Frequency Rating 50/60 Hz
 Manufacturer Part Number EK4235S
 Material Polycarbonate
 Mounting Type Box/Fixture
 Operating Cycles 10000 hr
 PART NUMBER KEYWORDS EK4235S ; 16884033 ; 078275152410 ; 78275152410 ; 07827515241 ; 00078275152410
 Sensitivity 1.5 FC Turn ON/4.5 FC Turn OFF
 Sensor Type Solid State Photo/Silicon IR Filtered
 Series EK4000 Series
 Standards/Approvals ANSI C136.24|CA Title 20|cULus Listed|PROP65: This product contains Nickel and DEHP known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov|CSA Approved
 Timing Range 2 to 5 s
 Tungsten Rating 1000 W
 Type Swivel
 Video Links
 Voltage Rating 480 V AC

Features

▪ Non-drift silicon light sensor with IR filter
▪ DC relay with zero-crossing circuitry for extended life
▪ Conformal coated PCB
▪ 15-year design life
▪ Exceeds 10,000 ON/OFF switching cycles
▪ Fail ON mode
