Emerson Electric
EFS110-2023M APP U-LINE RECEPT MALL IRON 78138139696

Mouse over image to zoom, click to enlarge

Description: Appleton® U-Line™ Pin and Sleeve Receptacle, 1-Gang Dead-End, 125 V AC, 20 A, 1 hp, 3 Pole, 2 Wires, NEMA 3/3R, Malleable Iron, 3 in W x 5.69 in D x 5.38 in H

Manufacturer PN: EFS110-2023M

UPC:  78138139696

Kendall Electric Inc PN: 2351457

Invoice Description:

EFS110-2023M APP U-LINE RECEPT MALL IRON 78138139696


SPEC SHEET

How Can We Make This Page Better?

Appleton® U-Line™ EFS110-2023M 1-Gang Dead-End Pin and Sleeve Receptacle With Mounting Box, 125 V AC, 20 A, 3 Poles, 2 Wires

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Appleton® U-Line™ Pin and Sleeve Receptacle, 1-Gang Dead-End, 125 V AC, 20 A, 1 hp, 3 Pole, 2 Wires, NEMA 3/3R, Malleable Iron, 3 in W x 5.69 in D x 5.38 in H

Specifications

 Amperage Rating 20 A
 Application For CPH/ECP mating plugs, lighting systems, conveyors, heaters, motor generator sets, air conditioners, compressors and pumps
 Brand Name Appleton
 Dimensions 3 in W x 5.69 in D x 5.38 in H
 Horsepower 1 hp
 Includes 1 in Hub
 Manufacturer Part Number EFS110-2023M
 Material Malleable Iron
 NEMA Rating NEMA 3/3R
 Number of Poles 3
 Number of Wires 2
 PART NUMBER KEYWORDS EFS110-2023M ; EFS1102023M ; 8337925 ; 781381396967 ; 78138139696 ; 00781381396967
 Standards/Approvals Class I, Division 1 And 2, Groups B, C, D; Class II, Division 1 And 2, Groups F, G; Class III; UL Listed: E10784, E81751; UL Standard: 1203, 1010, 894; CSA Standard: C22.2 No. 25, C22.2 No. 30, C22.2 No. 42, C22 No.159; CSA Certified: 038644
 Type 1-Gang Dead-End
 Voltage Rating 125 V AC

Features

▪ Constructional feature explosionproof and dust-ignitionproof
▪ External seals not required in most areas, arcing is safely confined to receptacle interior
▪ Suitable for use in class I, division 1, group B when used with external seals (seals must be placed within 2 in from each conduit opening, seals are not required in class I, division 2 locations)
▪ Spring cover, glass filled reinforced polyester insulating blocks
▪ Factory sealed
▪ Surface mount
