| ▪ Lockout provisions on front operated pushbutton (marked "STOP" and "OFF") and selector switch covers |
| ▪ Lockout hole for padlock having 1/4 in hasp is provided when used with covers for front lever and side rocker type operation |
| ▪ Close tolerances in machining of wide, mating flanges and journaled shafts and bearings for front button operation, produces flame tightness of enclosure joints |
| ▪ On enclosures with front lever and side rocker type operating handles, threaded type shafts and bushings are used to ensure flame tightness |
| ▪ When stop is indicated, button is automatically red, when start is indicated, button is automatically green, otherwise, black buttons are standard |
| ▪ Explosionproof, dust ignitionproof, raintight |
| ▪ 3/4 in hub |
| ▪ Two circuit |
| ▪ Fully assembled |
| ▪ For use with EDS/EFS series control stations |
| ▪ Factory sealed enclosures are used to prevent arcing of enclosed device from causing ignition of a hazardous atmosphere external to the enclosure, in conjunction with magnetic starters or contactors for remote control of motors |
| ▪ Reduce installation problem |
| ▪ Eliminate external seals |
| ▪ Lower installation cost |
| ▪ Improve safety |
| ▪ Are used with general purpose snap and pushbutton type switches |
| ▪ Standard neoprene covers for front operated pushbuttons prevents accumulation of dirt and entrance of water around operating shafts |
| ▪ Mounting lugs and taper tapped hubs with integral bushing |
| ▪ Large machine screws for fastening covers to bodies |
