Eaton
E34EX723BL CH 30MM 2POSITION SELECTOR SWITCH MAINTAINED BLACK KNOB 1NO/1NC SS-XO,OX NEMA4X/12 CLASSI/DIV2 CORROSION RESISTANT

Mouse over image to zoom, click to enlarge

  • E34EX723BL CH 30MM 2POSITION SELECTOR SWITCH MAINTAINED BLACK KNOB 1NO/1NC SS-XO,OX NEMA4X/12 CLASSI/DIV2 CORROSION RESISTANT
  • E34EX723BL CH 30MM 2POSITION SELECTOR SWITCH MAINTAINED BLACK KNOB 1NO/1NC SS-XO,OX NEMA4X/12 CLASSI/DIV2 CORROSION RESISTANT

Description: EATON Non-Illuminated Selector Switch, Assembled, Series: E34, 30.5 mm Size, 2NO-2NC Contact Configuration, Maintained Contact Mode, 10 A at 600 VAC/2.5 A at 250 VDC Contact, Lever Operator, 2 Positions, 60 deg Throw, Cam Code: 1, NEMA 3/3R/4/4X/12/13/IP65 Enclosure, Surface Mounting, Die Cast Zinc, Epoxy Powder Coated, Black, Environmental Conditions: 32 to 140 deg F Operating Temperature, 95% Relative Humidity at 60 deg C

Manufacturer PN: E34EX723BL

UPC:  78211453465

Kendall Electric Inc PN: 4444107

Invoice Description:

E34EX723BL CH 30MM 2POSITION SELECTOR SWITCH MAINTAINED BLACK KNOB 1NO/1NC SS-XO,OX NEMA4X/12 CLASSI/DIV2 CORROSION RESISTANT


SPEC SHEET

▸ See All in Explosionproof Selector Switches


How Can We Make This Page Better?

EATON E34EX723BL Assembled Non-Illuminated Selector Switch, 30.5 mm, 2NO-2NC Contact, Lever Operator, Black

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The two-layer, 100% solid thermosetting cathodic epoxy coating applied to these rugged, die cast pushbuttons provides a flat black, smooth, consistent and corrosion-resistant surface that has passed a demanding 600 hr salt spray test-four times longer than the industry-standard test.
EATON Non-Illuminated Selector Switch, Assembled, Series: E34, 30.5 mm Size, 2NO-2NC Contact Configuration, Maintained Contact Mode, 10 A at 600 VAC/2.5 A at 250 VDC Contact, Lever Operator, 2 Positions, 60 deg Throw, Cam Code: 1, NEMA 3/3R/4/4X/12/13/IP65 Enclosure, Surface Mounting, Die Cast Zinc, Epoxy Powder Coated, Black, Environmental Conditions: 32 to 140 deg F Operating Temperature, 95% Relative Humidity at 60 deg C

Specifications

 Application Electrical Assemblies, Panels and OEMs Applications
 Brand Name EATON
 Cam Code 1
 Color Black
 Contact Configuration 2NO-2NC
 Contact Rating 10 A at 600 VAC/2.5 A at 250 VDC
 Enclosure NEMA 3/3R/4/4X/12/13/IP65
 Environmental Conditions 32 to 140 deg F Operating Temperature, 95% Relative Humidity at 60 deg C
 Finish Epoxy Powder Coated
 Manufacturer Part Number E34EX723BL
 Material Die Cast Zinc
 Mounting Type Surface
 Number of Positions 2
 Series E34
 Size 30.5 mm
 Standards/Approvals CE Marked|CSA C22.2 No. 14|CSA C22.2 No. 213|CSA Certified|CSA File No. LR20713/M1987|CSA File No. LR68551|FDA 3-A Certified|NEC Class I Division 2 Groups B, C, D|UL 1604 File No. E10323|UL 505|UL 508|UL File No. E131568
 Throw 60 deg
 Type Assembled
 Video Links

Features

▪ Factory sealed contact blocks
▪ Heavy duty die cast zinc construction
▪ Front of panel drainage holes
▪ Grounding nibs on the operator casing
▪ Earth terminal provides additional grounding point and allows for daisy chain grounding
▪ Oiltight and corrosion-resistant (indoor/outdoor) environmental conditions
