Chemelex
E-150 CHEMELEX LOW PROFILE END SEAL KIT 979099-000

Mouse over image to zoom, click to enlarge

Description: RAYCHEM End Seal Kit, Cold-Applied Low Profile, For Use With: BTV-CR, BTV-CT, QTVR-CT, XTV-CT, KTV-CT Heating Cable

Manufacturer PN: E-150

UPC:  71562942007

Kendall Electric Inc PN: 2535835

Invoice Description:

E-150 CHEMELEX LOW PROFILE END SEAL KIT 979099-000


SPEC SHEET

▸ See All in Heat Trace Connector Kits


How Can We Make This Page Better?

RAYCHEM E-150 Cold-Applied Low Profile End Seal Kit, For Use With BTV-CR, BTV-CT, QTVR-CT, XTV-CT, KTV-CT Heating Cable

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The E-150 is a cold-applied low-profile end seal. It is designed for use with the following Raychem brand heating cables: BTV, QTVR, XTV, and KTV. Use the E-150 in applications with temperatures ranging from -60degF to 420degF (-50degC to 215degC). It is approved by FM, CSA, and PTB for use in hazardous locations. The unique design of the E-150 suits the demanding requirements of the industrial environment. The low-profile housing can be installed on pipes and other surfaces. A spring-loaded grommet makes a first seal to maintain a watertight connection, while the silicone-free, non-curing sealant used in the Raychem sealing boot adds a second seal, providing additional protection. The rugged construction makes the E-150 resistant to impact and suitable for high-temperature and chemical exposure. The end seal requires no heat source for installation and it is re-enterable, making maintenance fast and easy. Each kit contains all the necessary materials to do one end termination.
RAYCHEM End Seal Kit, Cold-Applied Low Profile, For Use With: BTV-CR, BTV-CT, QTVR-CT, XTV-CT, KTV-CT Heating Cable

Specifications

 Application For Chemical and Pharmaceutical, Food and Beverage, Marine, Mining, Power, Oil and Gas Industries
 Brand Name RAYCHEM
 Includes (1) End Seal Enclosure Housing, (1) Sealing Grommet Assembly, (1) Sealing Boot, (1) Identification label
 Manufacturer Part Number E-150
 PART NUMBER KEYWORDS E-150 ; E150 ; 979099-000 ; 979099000
 Standards/Approvals CSA Certified|FM Approved
 Suitable For Use With BTV-CR, BTV-CT, QTVR-CT, XTV-CT, KTV-CT Heating Cable
 Type Cold-Applied Low Profile

Features

▪ The connection kit shall have a spring loaded grommet to maintain a watertight connection
▪ The connection kit shall use a silicone-free, non-curing sealant to provide additional sealing
▪ The connection kit shall use rugged engineering plastics for impact resistance
▪ The connection kit shall have NEMA4X/IP66 rating to keep the connections dry and corrosion free
▪ The connection kit shall use cold applied materials and shall not require the use of a heat gun, torch or hot work permit for installation
▪ The connection kit shall be rated to a minimum installation temperature of -40 deg F, minimum usage temperature of -60 deg F and maximum pipe temperature of 420 deg F
▪ 277 VAC for FM, CSA and 254 VAC for PTB operating voltage
▪ Engineered black polymer end plate and shim, silicone rubber sealing grommet and core sealer, stainless steel screws, compression spring, reinforcement plate
▪ Engineered black polymer enclosure
