Schneider Electric
DTU325R SQD 400A DT SS 240V 3P

Mouse over image to zoom, click to enlarge

  • DTU325R SQD 400A DT SS 240V 3P
  • DTU325R SQD 400A DT SS 240V 3P
  • DTU325R SQD 400A DT SS 240V 3P
  • DTU325R SQD 400A DT SS 240V 3P

Description: Schneider Electric Square D™ Safety Switch, Double Throw Non-Fusible, 240 VAC/250 VDC, 400 A, 125 hp, 3 Poles, 200 kA Short Circuit, NEMA 3R Enclosure, Surface Mounting, 24 in W x 7.25 in D x 54.5 in H Dimensions

Manufacturer PN: DTU325R

UPC:  78590133144

Kendall Electric Inc PN: 4899570

Invoice Description:

DTU325R SQD 400A DT SS 240V 3P


SPEC SHEET

▸ See All in Double-Throw Disconnects


How Can We Make This Page Better?

Schneider Electric Square D™ DTU325R Double Throw Non-Fusible Safety Switch, 240 VAC/250 VDC, 400 A, 125 hp, 3 Poles

Log In for Pricing and Availability

Note: Lead times are estimates only




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

The Square D™ by Schneider Electric brand Double Throw Safety Switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. Double throw safety switches are designed for Residential, light commercial and industrial installations. Double throw safety switches transfer a load from one power source to another power source. 30A-100A F Series safety switches provide significantly higher levels of mechanical endurance than NEMA KS-1 or UL98 standards require and switches can be field-converted to transfer a power source from one load to another. These switches come in fusible or non-fusible configurations and my be padlocked in the ON-OFF positions. This Double Throw Safety Switch has a rated current of 400 A. This non-fusible disconnect switch is surface mounted. This Double Throw Safety Switch comply's to UL listed certifications. Dimensions for this product are 26.25 in H x 32.5 in W x 10.63 in D. This product comes with an 18 month warranty.
Schneider Electric Square D™ Safety Switch, Double Throw Non-Fusible, 240 VAC/250 VDC, 400 A, 125 hp, 3 Poles, 200 kA Short Circuit, NEMA 3R Enclosure, Surface Mounting, 24 in W x 7.25 in D x 54.5 in H Dimensions

Specifications

 Amperage Rating 400 A
 Brand Name Square D
 Dimensions 24 in W x 7.25 in D x 54.5 in H
 Enclosure NEMA 3R
 Horsepower 125 hp
 Manufacturer Part Number DTU325R
 Mounting Type Surface
 Number of Poles 3
 Short Circuit Current Rating 200 kA
 Standards/Approvals Green Premium™ Listed|REACH Compliant|RoHS Compliant|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
 Type Double Throw Non-Fusible
 Voltage Rating 240 VAC/250 VDC
