Hubbell
DR20WHI HUBBELL DECO RCPT COMM GRD 20A 125V 5-20R WH..

Mouse over image to zoom, click to enlarge

  • DR20WHI HUBBELL DECO RCPT COMM GRD 20A 125V 5-20R WH..
  • DR20WHI HUBBELL DECO RCPT COMM GRD 20A 125V 5-20R WH..
  • DR20WHI HUBBELL DECO RCPT COMM GRD 20A 125V 5-20R WH..
  • DR20WHI HUBBELL DECO RCPT COMM GRD 20A 125V 5-20R WH..
  • DR20WHI HUBBELL DECO RCPT COMM GRD 20A 125V 5-20R WH..

Description: Hubbell Wiring Device-Kellems Style Line®, DR20WHI, Straight Blade Receptacle, 1-Phase Duplex Self-Grounding Screw Mount, Series: Decorator, 125 V AC, 20 A, 1 hp, 2 Pole, 3 Wires, 5-20R NEMA Rating, Commercial/Specification Grade, -40 to 75 deg C, Side Wired Terminal, Nylon, White, 3.28 x 1.06 x 1.29 in Dimensions

Manufacturer PN: DR20WHI

UPC:  78358512790

Kendall Electric Inc PN: 2718342

Invoice Description:

DR20WHI HUBBELL DECO RCPT COMM GRD 20A 125V 5-20R WH..


SPEC SHEET

▸ See All in Straight Blade Receptacles


How Can We Make This Page Better?

Hubbell Wiring Device-Kellems Style Line® DR20WHI Decorator 1-Phase Duplex Self-Grounding Screw Mount Straight Blade Receptacle, 125 V AC, 20 A, 2 Poles, 3 Wires, White

Log In for Pricing and Availability




Description

Straight Blade Devices, Receptacles, Duplex, Decorator, Commercial/Industrial Grade, 2-Pole 3-Wire Grounding, 20A 125V, 5-20R, White, Single Pack.
Hubbell Wiring Device-Kellems Style Line®, DR20WHI, Straight Blade Receptacle, 1-Phase Duplex Self-Grounding Screw Mount, Series: Decorator, 125 V AC, 20 A, 1 hp, 2 Pole, 3 Wires, 5-20R NEMA Rating, Commercial/Specification Grade, -40 to 75 deg C, Side Wired Terminal, Nylon, White, 3.28 x 1.06 x 1.29 in Dimensions

Specifications

 Amperage Rating 20 A
 Brand Name Hubbell Premise Wiring
 Color White
 Dimensions 3.28 x 1.06 x 1.29 in
 Grade Commercial/Specification
 Horsepower 1 hp
 Manufacturer Part Number DR20WHI
 Material Nylon
 NEMA Rating 5-20R
 Number of Poles 2
 Number of Wires 3
 Series Decorator
 Standards/Approvals UL 498, File No. E2186 Listed|UL 94-V-2 Flammability Rating|CSA C22.2, No. 42|NEMA WD1/WD5/WD6 Compliant|RoHS Compliant
 Temperature Rating -40 to 75 deg C
 Terminal Type Side Wired
 Type 1-Phase Duplex Self-Grounding Screw Mount
 Voltage Rating 125 V AC

Features

▪ Aesthetic Style Line decorator design
▪ Triple wipe contacts
▪ Smooth face
