ABB
DALL-6-CG RED DOT SHRINK-WRP 2 LL BODY-CV-GSK

Mouse over image to zoom, click to enlarge

Description: Red Dot® Conduit Body, Type LL, Series: A Series, 2 in Hub, 2 Hubs, 69.5 cu-in, NPT/Set Screw, Die Cast Aluminum, 10-3/16 in L x 3-15/16 in W x 3-7/16 in H

Manufacturer PN: DALL-6-CG

UPC:  04226900359

Kendall Electric Inc PN: 2327188

Invoice Description:

DALL-6-CG RED DOT SHRINK-WRP 2 LL BODY-CV-GSK


SPEC SHEET

▸ See All in Conduit Bodies - Type LL


How Can We Make This Page Better?

Red Dot® DALL-6-CG A Series Type LL Conduit Body With Cover, Gasket, 2 in Hub, 69.5 cu-in Capacity, Die Cast Aluminum

Log In for Pricing and Availability




Description

Preferred for more than 50 years, Red Dot® weatherproof and conduit body solutions withstand the harshest elements and ensure trouble free installation and years of superior performance.
Red Dot® Conduit Body, Type LL, Series: A Series, 2 in Hub, 2 Hubs, 69.5 cu-in, NPT/Set Screw, Die Cast Aluminum, 10-3/16 in L x 3-15/16 in W x 3-7/16 in H

Specifications

 Application For rigid/IMC conduit
 Brand Name Steel City®
 Connection Type NPT/Set Screw
 Dimensions 10-3/16 in L x 3-15/16 in W x 3-7/16 in H
 Hub Size 2 in
 Manufacturer Part Number DALL-6-CG
 Material Die Cast Aluminum
 Number of Hubs 2
 PART NUMBER KEYWORDS DALL-6-CG ; DALL6CG ; 7TAA118140R0003 ; 10738882 ; 042269003590 ; 42269003590 ; 04226900359 ; 00042269003590 ; 5415022250671
 Series A Series
 Standards/Approvals UL File No. E28688
 Type Type LL

Features

▪ Combination packaging of conduit body, cover and gasket reduces handling and inventory costs
▪ Expanded line covers hub sizes from 1/2 to 4 in
▪ See through wrapper provides instant identification and protects product on job site
▪ Threaded conduit bodies maintain a weather-resistant conduit system when used with covers and gaskets
▪ Left side access opening
▪ Spacious, accessible wiring chamber provides a convenient location to pull conductors and make splices
▪ Red Dot® quality in durable, die cast aluminum construction made to endure the elements

Resources

 Catalog Page
 Product Data Sheet
