CSPB4236 HOFFMAN PANEL, SWING OUT, 42X36 78351016507

Mouse over image to zoom, click to enlarge

Description: Hoffman CONCEPT™ Concept Swing Out Panel, Series: CWY, 39.72 in Width, 33-3/4 in Height, For Use With: CONCEPT™ 42 x 36 in Enclosures, Steel, Painted, White

Manufacturer PN: CSPB4236

UPC:  78351016507

Kendall Electric Inc PN: 3619213

Invoice Description:

CSPB4236 HOFFMAN PANEL, SWING OUT, 42X36 78351016507


SPEC SHEET

▸ See All in Enclosure Swing-Out Panels


How Can We Make This Page Better?

Hoffman CONCEPT™ CSPB4236 CWY Concept Swing Out Panel, 39.72 in W x 33-3/4 in H, For Use With CONCEPT™ 42 x 36 in Enclosures, Steel

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Panels swing clear from the front of the enclosure to provide access to mounted internal equipment. For CSPB panels, maximum swing is 94 degrees. For CSP panels, maximum panel swing is 106 degrees. Distance from panel surface to door when in the latched position is 1.71 in. (43 mm) for solid doors and 1.45 in. (37 mm) for window doors. Kits include panel, brackets and hardware to mount to the front flange. Swing-out panels also can be mounted on front-to-back adjustable rails. CSPB panels require adapter CSPBADB and front-to-back adjustable rails for front-to-back adjustment.
Hoffman CONCEPT™ Concept Swing Out Panel, Series: CWY, 39.72 in Width, 33-3/4 in Height, For Use With: CONCEPT™ 42 x 36 in Enclosures, Steel, Painted, White

Specifications

 Brand Name nVent HOFFMAN
 Color White
 Finish Painted
 Height 33-3/4 in
 Includes Panel, Brackets and Hardware
 Manufacturer Part Number CSPB4236
 Material Steel
 PART NUMBER KEYWORDS CSPB4236 ; 16507 ; 9541260 ; 783510165079 ; 78351016507 ; 00783510165079
 Series CWY
 Standards/Approvals RoHS Compliant|REACH Compliant
 Suitable For Use With CONCEPT™ 42 x 36 in Enclosures
 Width 39.72 in

Features

▪ CSP panels, maximum panel swing is 106 deg
▪ Distance from panel surface to door when in the latched position is 1.71 in (43 mm) for solid doors and 1.45 in (37 mm) for window doors
