ABB
CR463L04AJA10A0 GE LIGHTING CONTACTOR-ENCLOSED

Mouse over image to zoom, click to enlarge

  • CR463L04AJA10A0 GE LIGHTING CONTACTOR-ENCLOSED
  • CR463L04AJA10A0 GE LIGHTING CONTACTOR-ENCLOSED
  • CR463L04AJA10A0 GE LIGHTING CONTACTOR-ENCLOSED
  • CR463L04AJA10A0 GE LIGHTING CONTACTOR-ENCLOSED

Description: GE Lighting Contactor, Electrically Held Standard Control, Series: CR460 Series, 110/115 to 120 VAC Coil, 30 A Maximum Load Current, 4 Poles, 50/60 Hz, Auxiliary Contact, 4NC, 4 Auxiliary Contacts, A600, 10 A at 600 V AC Contact, Finger Safe Terminal, Enclosed/NEMA 1, -25 to 40 deg C Operating, Surface Mount, 10 in H x 4.62 in W x 10 in D

Manufacturer PN: CR463L04AJA10A0

UPC:  78316662420

Kendall Electric Inc PN: 4715626

Invoice Description:

CR463L04AJA10A0 GE LIGHTING CONTACTOR-ENCLOSED


SPEC SHEET

▸ See All in Lighting Contactors


How Can We Make This Page Better?

GE CR463L04AJA10A0 CR460 Series Electrically Held Standard Control Lighting Contactor, 110/115 to 120 VAC Coil, 30 A, 4NC, 4 Poles

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The ultimate in versatility, simplicity and performance. All CR460 Series lighting contactors deliver unprecedented versatility in application, simplicity in configuration and performance in operation. Their revolutionary design and unique features meet most lighting control needs better than ever before.
GE Lighting Contactor, Electrically Held Standard Control, Series: CR460 Series, 110/115 to 120 VAC Coil, 30 A Maximum Load Current, 4 Poles, 50/60 Hz, Auxiliary Contact, 4NC, 4 Auxiliary Contacts, A600, 10 A at 600 V AC Contact, Finger Safe Terminal, Enclosed/NEMA 1, -25 to 40 deg C Operating, Surface Mount, 10 in H x 4.62 in W x 10 in D

Specifications

 Application For switch ballast (fluorescent or HID), tungsten, general use load, carry motor load, resistive, pilot duty rating, electrical distribution and control applications
 Brand Name GE
 Coil Voltage 110/115 to 120 V AC
 Contact Configuration 4NC
 Contact Rating A600, 10 A at 600 V AC
 Contact Type Auxiliary
 Dimensions 10 in H x 4.62 in W x 10 in D
 Enclosure Enclosed/NEMA 1
 Frequency Rating 50/60 Hz
 Manufacturer Part Number CR463L04AJA10A0
 Maximum Load Current 30 A
 Mounting Type Surface
 Number of Auxiliary Contacts 4
 Number of Poles 4
 Operating Temperature -25 to 40 deg C
 PART NUMBER KEYWORDS CR463L04AJA10A0 ; 7634642 ; 783166624203 ; 78316662420 ; 00783166624203
 Series CR460 Series
 Standards/Approvals ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL 508 File No. E1811|cUL Listed|CE Certified
 Terminal Type Finger Safe
 Type Electrically Held Standard Control

Features

▪ Robust pole terminals accept up to two #8 AWG wires
▪ Manual operator, fast, sure 3-point mounting
▪ Enclosed contacts resist contaminants for greater reliability
▪ Combination slotted/#2 Phillips® screws
▪ Common, easily installed power poles change from NO to NC (or vice versa) simply by unlatching and rotating 180 deg
▪ Power poles rated for the range of tasks 30 A rated contacts, 15 A motor rated, A600 pilot duty rated
▪ Easy to read rating label
▪ Auxiliary contacts, rated A600 are suitable for use on low level circuits down to 12 VAC, 5 mA
▪ 110 VAC at 50 Hz, 115 to 120 VAC at 60 Hz coil voltage
▪ Without additional auxiliary contact, 30 mm pilot device, 30 mm pilot light, control power transformer
▪ Standard assembled forms
▪ Modular design permits fast, on-site configuration
▪ Snap-in auxiliary contacts
▪ Continuously rated, interchangeable coils
▪ Contact position indication when button protrudes, contact is closed
▪ Convenient side access field power wiring
▪ Contact configuration indicator
▪ Standard base for all pole configurations
