Eaton
FAZ-C7/3-RT CH FAZ UL 489 MCB 3P 7A C CURVE RING TERMINAL

Mouse over image to zoom, click to enlarge

  • FAZ-C7/3-RT CH FAZ UL 489 MCB 3P 7A C CURVE RING TERMINAL
  • FAZ-C7/3-RT CH FAZ UL 489 MCB 3P 7A C CURVE RING TERMINAL
  • FAZ-C7/3-RT CH FAZ UL 489 MCB 3P 7A C CURVE RING TERMINAL
  • FAZ-C7/3-RT CH FAZ UL 489 MCB 3P 7A C CURVE RING TERMINAL

Description: EATON Miniature Circuit Breaker, Series: FAZ-RT, 277/480 V AC, 7 A, 50/60 Hz Frequency, 10 to 14 kA Interrupt, Thermal Magnetic Trip, 3 Pole, Ring Tongue Connection, DIN Rail Mounting, 4.13 in H x 2.09 in W x 2.97 in D Dimensions;EATON Miniature Circuit Breaker, Series: FAZ-RT, 277/480 V AC, 30 A, 50/60 Hz Frequency, 10 to 14 kA Interrupt, Thermal Magnetic Trip, 3 Pole, Ring Tongue Connection, DIN Rail Mounting, 4.13 in H x 2.09 in W x 2.97 in D Dimensions

Manufacturer PN: FAZ-C7/3-RT

UPC:  01508102161

Kendall Electric Inc PN: 3655938

Invoice Description:

FAZ-C7/3-RT CH FAZ UL 489 MCB 3P 7A C CURVE RING TERMINAL


SPEC SHEET

How Can We Make This Page Better?

EATON FAZ-C7/3-RT FAZ-RT Miniature Circuit Breaker, 277/480 V AC, 7 A, 10 to 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip;EATON FAZ-C30/3-RT FAZ-RT Miniature Circuit Breaker, 277/480 V AC, 30 A, 10 to 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Eaton's FAZ, dual rated UL and IEC circuit breakers are ideal for providing protection in many applications. A current limiting design provides fast short-circuit interruption, offering superior protection by reducing peak let-through current. Superior product quality, tested reliability and safety make Eaton’s UL 1053 Residual Current Circuit Breaker (RCCB) the optimum product for residual current applications. The UL 1053 RCCB circuit breakers provide safety and protection for personnel and equipment.
EATON Miniature Circuit Breaker, Series: FAZ-RT, 277/480 V AC, 7 A, 50/60 Hz Frequency, 10 to 14 kA Interrupt, Thermal Magnetic Trip, 3 Pole, Ring Tongue Connection, DIN Rail Mounting, 4.13 in H x 2.09 in W x 2.97 in D Dimensions;EATON Miniature Circuit Breaker, Series: FAZ-RT, 277/480 V AC, 30 A, 50/60 Hz Frequency, 10 to 14 kA Interrupt, Thermal Magnetic Trip, 3 Pole, Ring Tongue Connection, DIN Rail Mounting, 4.13 in H x 2.09 in W x 2.97 in D Dimensions

Specifications

 Amperage Rating 7 A;30 A
 Application Circuit Protection, Convenience Receptacle Circuits, Motor Control Circuits, HACR Internal/External Equipment, PLC I/O Points, Computers, Power Supplies, Control Instrumentation, Relays, UPS, Power Conditioners and Industrial Applications
 Brand Name EATON
 Connection Type Ring Tongue
 Dimensions 4.13 in H x 2.09 in W x 2.97 in D
 Frequency Rating 50/60 Hz
 Manufacturer Part Number FAZ-C7/3-RT;FAZ-C30/3-RT
 Mounting Type DIN Rail
 Number of Poles 3
 PART NUMBER KEYWORDS FAZ-C7/3-RT ; FAZC73RT ; 11231962 ; 04015081021611 ; 4015081021611;FAZ-C30/3-RT ; FAZC303RT ; 11231970 ; 04015081021697 ; 4015081021697
 Series FAZ-RT
 Standards/Approvals CSA Std. C22.2 No.235,IEC 60947-2,UL 1077;CSA Std. C22.2 No.235,UL 1077,IEC 60947-2
 Voltage Rating 277/480 V AC

Features

▪ Current limiting design provides fast short circuit interruption that reduces let through energy, which can damage the circuit
▪ Suitable for branch circuit device protection
▪ Thermal magnetic overcurrent protection
▪ Three levels of shortcircuit protection, categorized by B, C and D curves
▪ Trip free design breaker can not be defeated by holding the handle in the ON position
▪ Captive screws cannot be lost
▪ Field installable shunt trip and auxiliary switch subsequent mounting
▪ Contact position indicator red - green
▪ Possibility for sealing the toggle in "ON or OFF" position
