  • CMRPDT9 SENSORSWITCH STANDARD RANGE, DUAL TECHNOLOGY 360 SENSOR (CI 184CHA)
  • CMRPDT9 SENSORSWITCH STANDARD RANGE, DUAL TECHNOLOGY 360 SENSOR (CI 184CHA)
  • CMRPDT9 SENSORSWITCH STANDARD RANGE, DUAL TECHNOLOGY 360 SENSOR (CI 184CHA)
  • CMRPDT9 SENSORSWITCH STANDARD RANGE, DUAL TECHNOLOGY 360 SENSOR (CI 184CHA)
  • CMRPDT9 SENSORSWITCH STANDARD RANGE, DUAL TECHNOLOGY 360 SENSOR (CI 184CHA)

Description: Sensor Switch™, CMR PDT 9, Ceiling Mount Occupancy Sensor, Line Voltage, Series: CM PDT, 120/277 V AC, 16 mA, PDT Sensor, 12 ft Coverage, 360 deg Viewing, 30 s to 30 min Time Delay, 50/60 Hz Response, Wired Connection, Ceiling Mounting, 14 to 160 deg F, Plastic, Matte White, 4.55 in Dia x 1.55 in D Dimensions

Manufacturer PN: CMRPDT9

UPC:  74597580944

Kendall Electric Inc PN: 2714475

Invoice Description:

CMRPDT9 SENSORSWITCH STANDARD RANGE, DUAL TECHNOLOGY 360 SENSOR (CI 184CHA)


SPEC SHEET

How Can We Make This Page Better?

Sensor Switch™ CMR PDT 9 CM PDT Line Voltage Ceiling Mount Occupancy Sensor, 120/277 V AC, PDT Sensor, 12 ft Coverage, 360 deg Viewing, Ceiling Mounting

Log In for Pricing and Availability




Description

The CMR is a line voltage sensor that easily mounts directly to a ceiling. Ceiling mount sensors are offered in a multitude of configurations which address many applications. Lens options include large motion extended range, small motion standard range and bi-directional for hallways. These sensors are capable of covering an entire private office or small room by themselves.
Sensor Switch™, CMR PDT 9, Ceiling Mount Occupancy Sensor, Line Voltage, Series: CM PDT, 120/277 V AC, 16 mA, PDT Sensor, 12 ft Coverage, 360 deg Viewing, 30 s to 30 min Time Delay, 50/60 Hz Response, Wired Connection, Ceiling Mounting, 14 to 160 deg F, Plastic, Matte White, 4.55 in Dia x 1.55 in D Dimensions

Specifications

 Amperage Rating 16 mA
 Application Automotive and Parking, Education, Government, Healthcare, Hospitality, Manufacturing, Offices and Banks, Power and Gas, Religious, Residential, Retail, Roadways, Bridges and Tunnels, Sports and Recreation, Transportation, Warehouses Applications
 Brand Name Sensor Switch
 Color Matte White
 Connection Type Wired
 Coverage 12 ft
 Dimensions 4.55 in Dia x 1.55 in D
 Manufacturer Part Number CMR PDT 9
 Material Plastic
 Mounting Type Ceiling
 PART NUMBER KEYWORDS CMR PDT 9 ; CMRPDT9 ; 184CHA ; 10600869 ; 13090467 ; 745975809448 ; 74597580944 ; 00745975809448
 Response Frequency 50/60 Hz
 Sensor Type PDT
 Series CM PDT
 Standards/Approvals cULus Listed
 Temperature Rating 14 to 160 deg F
 Time Delay 30 s to 30 min
 Type Line Voltage
 Video Links
 Viewing Angle 360 deg
 Voltage Rating 120/277 V AC

Features

▪ Lens options include large motion extended range, small motion standard range and bi-directional for hallways
▪ These sensors are capable of covering an entire private office or small room by themselves
▪ ENERGY SAVINGS - Self-contained relay (no power pack needed)
▪ COMPATIBLE - Enjoy the flexibility and convenience of programming sensor settings with your smartphone using the SensorSwitch Mobile App through camera flash programming
▪ MOUNTING - 12 ft radial coverage when mounted to standard 9 ft ceiling, 8-15 ft mounting heights provide 10-20 ft radial coverage
▪ MOTION DETECTION - Best choice for small motion detection
▪ LAMP - 100 hr lamp burn-in timer mode
