Eaton
CMBB150BTS CH METER-MAIN 3/4 150A MAIN BBKR BOTTOM/TOP FEED SURFACE

Mouse over image to zoom, click to enlarge

  • CMBB150BTS CH METER-MAIN 3/4 150A MAIN BBKR BOTTOM/TOP FEED SURFACE
  • CMBB150BTS CH METER-MAIN 3/4 150A MAIN BBKR BOTTOM/TOP FEED SURFACE
  • CMBB150BTS CH METER-MAIN 3/4 150A MAIN BBKR BOTTOM/TOP FEED SURFACE

Description: EATON Cutler-Hammer Meter Breaker, Type CH Non-EUSERC 1-Socket, 120/240 V AC, 200 A, 1 ph, Bottom/Overhead/Top/Underground Feed, 4 Jaws, 6 AWG to 250 kcmil Wire, Ring Cover, Surface Mounting, NEMA 3R Enclosure, 5.38 in L x 14.44 in W x 28.38 in H Dimensions

Manufacturer PN: CMBB150BTS

UPC:  78211360180

Kendall Electric Inc PN: 4730733

Invoice Description:

CMBB150BTS CH METER-MAIN 3/4 150A MAIN BBKR BOTTOM/TOP FEED SURFACE


SPEC SHEET

▸ See All in Meter Socket Circuit Breaker Combination


How Can We Make This Page Better?

EATON CMBB150BTS Type CH Non-EUSERC 1-Socket Cutler-Hammer Meter Breaker, 120/240 V AC, 200 A, 1 Phase, NEMA 3R Enclosure

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Eaton's Residential Meter Breakers save time and cost by providing contractors with all-in-one service entrance equipment. They allow for quick, flexible, simple installation, and can be used with BR- or CH-type branch circuit breaker styles. Constructed to be a self-contained durable enclosure and meet the latest NEC wire bending space requirements, they are particularly useful for residential metering in areas where utilities are deregulated, and the electrical contractor has to supply watt-hour meter sockets.
EATON Cutler-Hammer Meter Breaker, Type CH Non-EUSERC 1-Socket, 120/240 V AC, 200 A, 1 ph, Bottom/Overhead/Top/Underground Feed, 4 Jaws, 6 AWG to 250 kcmil Wire, Ring Cover, Surface Mounting, NEMA 3R Enclosure, 5.38 in L x 14.44 in W x 28.38 in H Dimensions

Specifications

 Amperage Rating 200 A
 Application Residential, Electrical Assemblies, Panels and OEMs Applications
 Brand Name EATON
 Cover Type Ring
 Dimensions 5.38 in L x 14.44 in W x 28.38 in H
 Enclosure NEMA 3R
 Feed Type Bottom/Overhead/Top/Underground
 Manufacturer Part Number CMBB150BTS
 Mounting Type Surface
 Number of Jaws 4
 Phase 1
 Standards/Approvals UL Listed
 Type Type CH Non-EUSERC 1-Socket
 Voltage Rating 120/240 V AC

Features

▪ Larger 250 kcmil lugs and additional knockouts for ease of installation
