Acuity Brands
CM9ADC LITHONIA OCCUPANCY SENSOR (CI# 184ETW)

Mouse over image to zoom, click to enlarge

  • CM9ADC LITHONIA OCCUPANCY SENSOR (CI# 184ETW)
  • CM9ADC LITHONIA OCCUPANCY SENSOR (CI# 184ETW)
  • CM9ADC LITHONIA OCCUPANCY SENSOR (CI# 184ETW)
  • CM9ADC LITHONIA OCCUPANCY SENSOR (CI# 184ETW)

Description: Sensor Switch™ Occupancy Sensor, Series: CM Series, 12 to 24 V AC/DC, Passive Infrared Sensor, 360 deg Viewing, Ceiling Mount, White, 4.55 in Dia x 1.55 in D

Manufacturer PN: CM9ADC

UPC:  74597585895

Kendall Electric Inc PN: 3749000

Invoice Description:

CM9ADC LITHONIA OCCUPANCY SENSOR (CI# 184ETW)


SPEC SHEET

▸ See All in Wireless Occupancy Sensors


How Can We Make This Page Better?

Sensor Switch™ CM 9 ADC Occupancy Sensor With Auto Dimming, 12 to 24 V AC/DC, Passive Infrared Sensor, 360 deg, Ceiling Mount

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The Wall Sensor Switch uses passive infrared technology to automatically turn lights on and off. By using sensors, energy consumption and costs are greatly reduced. The sensors detect body heat in motion and must be located where full line-of-sight is possible.
Sensor Switch™ Occupancy Sensor, Series: CM Series, 12 to 24 V AC/DC, Passive Infrared Sensor, 360 deg Viewing, Ceiling Mount, White, 4.55 in Dia x 1.55 in D

Specifications

 Application Cafeteria, Classroom, Closet/Storage Room, Conference Room, Examination Room, Hospital, Kitchen, Living Area, Locker Room, Open Office, Patient Room, Private Office and Restroom
 Brand Name Sensor Switch
 Color White
 Dimensions 4.55 in Dia x 1.55 in D
 Manufacturer Part Number CM 9 ADC
 Mounting Type Ceiling
 PART NUMBER KEYWORDS CM 9 ADC ; CM9ADC ; 184ETW ; 10713457 ; 745975858958 ; 74597585895 ; 00745975858958
 Sensor Type Passive Infrared
 Series CM Series
 Standards/Approvals cULus|UL Listed
 Viewing Angle 360 deg
 Voltage Rating 12 to 24 V AC/DC

Features

▪ Small motion/standard range 360 deg lens
▪ The CM is a low voltage sensor that easily mounts directly to a ceiling tile or a metallic grid
▪ Push- button programmable, adjustable time delays, and multiple operating modes
▪ 100 hr lamp burn-in timer mode
▪ No field calibration or sensitivity adjustments required
▪ Convenient test mode
▪ Green LED status Indicator
▪ Photocell with dimming
▪ Standard temperature/humidity
▪ Photo control
