Eaton

CHN240GF CH CH 5MA GFCI, 2P, 40A, 120/240V, 10KAIC "PON LOADCENTER"

Mouse over image to zoom, click to enlarge

Description: EATON Ground Fault Circuit Breaker, 120/240 V, 40 A, 10 kA Interrupt, Thermal Magnetic Trip, 5 mA Trip, 2 Pole, Plug-In Connection, 6 in L x 3-1/2 in W x 2-1/4 in H Dimensions

Manufacturer PN: CHN240GF

UPC: 78668921726

Kendall Electric Inc PN: 4078572

Invoice Description:

CHN240GF CH CH 5MA GFCI, 2P, 40A, 120/240V, 10KAIC "PON LOADCENTER"

SPEC SHEET

▸ See All in Ground-Fault Circuit Breakers

How Can We Make This Page Better?

EATON CHN240GF Ground Fault Circuit Breaker, 120/240 V, 40 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip

Description Specifications Resources

Description

Eaton's residential CH circuit breakers provide premium overload protection. The Type CH circuit breakers trip to the OFF position, eliminating nuisance callbacks. The CHF family also includes a trip flag to differentiate between a trip and the breaker being turned off. The thermal-magnetic trip curve avoids nuisance tripping on mild overloads while reacting almost instantaneously to severe short-circuit conditions. Multiple breakers have an internal common trip connection to operate all poles simultaneously. Handles are marked with ON-OFF indication and ampere rating of the breaker.

EATON Ground Fault Circuit Breaker, 120/240 V, 40 A, 10 kA Interrupt, Thermal Magnetic Trip, 5 mA Trip, 2 Pole, Plug-In Connection, 6 in L x 3-1/2 in W x 2-1/4 in H Dimensions

Specifications

Amperage Rating	40 A
Application	Generation - Renewable Energy, Alternative Energy, Conventional Energy, Marine Vessels and Equipment, Datacenters, IT Space, CI and Hyper Converged Applications
Brand Name	EATON
Connection Type	Plug-In
Dimensions	6 in L x 3-1/2 in W x 2-1/4 in H
Manufacturer Part Number	CHN240GF
Number of Poles	2
Standards/Approvals	UL 489
Trip Range	5 mA
Voltage Rating	120/240 V
