CEP-FS30CC3 SHAWMUT 1P 30A 240V DIS-SW

Mouse over image to zoom, click to enlarge

  • CEP-FS30CC3 SHAWMUT 1P 30A 240V DIS-SW
  • CEP-FS30CC3 SHAWMUT 1P 30A 240V DIS-SW

Description: Mersen, CEP-FS30CC3, Fused Disconnect, Compact, Series: CEP, 600 VAC, 250 VDC, 30 A, 3, 5, 7.5 hp, 3 Pole, 200 kA Short Circuit, IP20 Enclosure, DIN Rail Mounting, 3.65 in L x 2.08 in W x 3.4 in H Dimensions

Manufacturer PN: CEP-FS30CC3

UPC:  78200150044

Kendall Electric Inc PN: 4159484

Invoice Description:

CEP-FS30CC3 SHAWMUT 1P 30A 240V DIS-SW


SPEC SHEET

▸ See All in Special Application Disconnects


How Can We Make This Page Better?

Mersen CEP-FS30CC3 CEP Compact Fused Disconnect, 600 VAC, 250 VDC, 30 A, 3, 5, 7.5 hp, 3 Poles

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Mersen’s Compact Fused Disconnect incorporates the switch functionality with the high protection level of a fuse. The switch accepts UL class CC fuses up to 30A. In addition to this, the Compact Fused Disconnect is UL 98 listed and suitable for use as main/feeder device and, in conjunction with CC fuses, is rated for branch circuit protection. It has a smaller footprint compared to a traditional Class CC disconnect with a max interrupting rating of 200kA. The compact form factor and ease of installation makes it a great choice for panel builders. The easy lockout/tagout feature and IP20 rating ensures additional safety along with the built in switch capability.
Mersen, CEP-FS30CC3, Fused Disconnect, Compact, Series: CEP, 600 VAC, 250 VDC, 30 A, 3, 5, 7.5 hp, 3 Pole, 200 kA Short Circuit, IP20 Enclosure, DIN Rail Mounting, 3.65 in L x 2.08 in W x 3.4 in H Dimensions

Specifications

 Amperage Rating 30 A
 Application For use as main/feeder device and in conjunction with CC fuses, Is rated for branch circuit protection
 Brand Name Mersen
 Dimensions 3.65 in L x 2.08 in W x 3.4 in H
 Enclosure IP20
 Horsepower 3, 5, 7.5 hp
 Manufacturer Part Number CEP-FS30CC3
 Mounting Type DIN Rail
 Number of Poles 3
 Series CEP
 Short Circuit Current Rating 200 kA
 Standards/Approvals cULus Listed File No. E191605|UL 98|CSA C22.2 No.4|IEC 60529|RoHS Compliant
 Type Compact
 Voltage Rating 600 VAC/250 VDC

Features

▪ Mersen's Compact Fused Disconnect incorporates the switch functionality with the high protection level of a fuse
▪ The compact form factor and ease of installation makes it a great choice for panel builders
▪ The easy lockout/tagout feature and IP20 rating ensures additional safety along with the built in switch capability
▪ 30A Fused disconnect
▪ Smaller footprint compared to a traditional Class CC disconnect
▪ 35mm DIN rail mounted
▪ Built-in lockout/tagout feature
▪ 75 deg C CU Wire
