Eaton
CCV2200X CH MAIN CIRCUIT BREAKER 2P 200 AMP 120/240V..

Mouse over image to zoom, click to enlarge

  • CCV2200X CH MAIN CIRCUIT BREAKER 2P 200 AMP 120/240V..
  • CCV2200X CH MAIN CIRCUIT BREAKER 2P 200 AMP 120/240V..

Description: EATON Main Circuit Breaker, Type CCV Tenant, 120/240 V AC, 200 A, 10 kA Interrupt, Thermal Magnetic Trip, 2 Pole, 1 ph, Load Connection, 2/0 AWG to 300 kcmil Copper/Aluminum Wire, Bolted-On Mounting, 60 to 75 deg C, 8 in L x 4-1/2 in W x 5-1/2 in H Dimensions

Manufacturer PN: CCV2200X

UPC:  78668536858

Kendall Electric Inc PN: 2772432

Invoice Description:

CCV2200X CH MAIN CIRCUIT BREAKER 2P 200 AMP 120/240V..


SPEC SHEET

▸ See All in Std Thermal Magnetic Circuit Breakers


How Can We Make This Page Better?

EATON CCV2200X Type CCV Tenant Main Circuit Breaker, 120/240 V AC, 200 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip

Log In for Pricing and Availability




Description

Eaton's main circuit breakers are used in a variety of applications including the main or emergency disconnect on the outside of a house, a tenant main breaker in group metering stacks and feed-through lug blocks specifically designed for sub-feeding from an existing panel. Main breakers are available with a variety of accessories including shunt trip, bell alarms and auxiliary switches.
EATON Main Circuit Breaker, Type CCV Tenant, 120/240 V AC, 200 A, 10 kA Interrupt, Thermal Magnetic Trip, 2 Pole, 1 ph, Load Connection, 2/0 AWG to 300 kcmil Copper/Aluminum Wire, Bolted-On Mounting, 60 to 75 deg C, 8 in L x 4-1/2 in W x 5-1/2 in H Dimensions

Specifications

 Amperage Rating 200 A
 Application For use on Type ECC Unit enclosures
 Brand Name EATON
 Connection Type Load
 Dimensions 8 in L x 4-1/2 in W x 5-1/2 in H
 Manufacturer Part Number CCV2200X
 Mounting Type Bolted-On
 Number of Poles 2
 PART NUMBER KEYWORDS CCV2200X ; 10782877 ; 786685368580 ; 78668536858 ; 00786685368580
 Phase 1
 Standards/Approvals UL 489
 Temperature Rating 60 to 75 deg C
 Type Type CCV Tenant
 Voltage Rating 120/240 V AC

Features

▪ Indirectly heated thermal tripping bi-metal elements
▪ Standard terminal lugs (wire connectors) suitable for copper or aluminum wire
▪ Backward compatibility type CCV and CCVH retains same profile and footprint as the CC and CCH breaker, allowing use in the same applications

Resources

 Catalog Page
 Product Data Sheet
