| ▪ FCF25RN, FCF30RN non-indicating fast acting |
| ▪ 200 kA at VAC, 100 kA at VDC short circuit current rating |
| ▪ 1.5 hp at 120 VAC, 3 hp at 240 VAC hp rating |
| ▪ Uses finger safe class CF CUBEFuse™ with class J performance |
| ▪ Extremely compact design at 25.4 mm W per pole |
| ▪ IP20 finger safe construction with 10 AWG wire or larger |
| ▪ Padlockable handle for lockout/tagout procedures |
| ▪ Box lug and fork terminal suitable for line, load or accessory connection |
| ▪ 4 mm shank lock or standard pin-out devices lockout/tag out |
| ▪ 18 to 10 AWG 20 lb-in, 8 to 4 AWG 35 lb-in torque at 0 to 60 A |
| ▪ Lock-on provision |
| ▪ Patented ampacity rejection feature helps prevent overfusing |
| ▪ High 200 kA short circuit current ratings |
| ▪ Disconnect rated to provide means for load isolation |
| ▪ Open fuse indication light per pole |
| ▪ Additional open fuse indication can be provided by using the time delay indicating CUBEFuse™ version |
| ▪ Built-in switch/fuse interlock prohibits fuse removal while energized |
| ▪ Permanent lockout/tagout provisions |
| ▪ TCF25RN, TCF30RN non-indicating time delay |
| ▪ TCF25, TCF30 indicating time delay |
