Eaton
C25DND330B CH OPEN N-R 3P 30A DP CONT SCR/PP W/QC TERM 240VAC COIL

Mouse over image to zoom, click to enlarge

  • C25DND330B CH OPEN N-R 3P 30A DP CONT SCR/PP W/QC TERM 240VAC COIL
  • C25DND330B CH OPEN N-R 3P 30A DP CONT SCR/PP W/QC TERM 240VAC COIL
  • C25DND330B CH OPEN N-R 3P 30A DP CONT SCR/PP W/QC TERM 240VAC COIL

Description: EATON Definite Purpose Control Contactor, D-Frame Non-Reversing, 208 to 240 V AC at 50/60 Hz Coil, 30 A Inductive/40 A Resistive Maximum Load Current, 5, 10 hp Coil, 3 Pole, Double Break Contact, Quick-Connect (Side by Side) Connection, Pressure Plate/Screw Terminal, Open Enclosure, 300000 Cycles Operating Cycles, 150 deg F Operating, Surface Mounting, 3.35 in L x 2.4 in W x 3.75 in H Dimensions

Manufacturer PN: C25DND330B

UPC:  78211630061

Kendall Electric Inc PN: 2125120

Invoice Description:

C25DND330B CH OPEN N-R 3P 30A DP CONT SCR/PP W/QC TERM 240VAC COIL


SPEC SHEET

▸ See All in Definite Purpose Contactors AC


How Can We Make This Page Better?

EATON C25DND330B D-Frame Non-Reversing Definite Purpose Control Contactor With Metal Mounting Plate, 208 to 240 V AC at 50/60 Hz V Coil, 30 A Inductive/40 A Resistive, 3 Poles

Log In for Pricing and Availability




Description

Definite purpose starters are electrically operated switching devices specifically designed for the heating, ventilation, air conditioning and refrigeration (HVAC) industry. They are controlled by automatic thermostat control or manual pushbutton interfaces.
EATON Definite Purpose Control Contactor, D-Frame Non-Reversing, 208 to 240 V AC at 50/60 Hz Coil, 30 A Inductive/40 A Resistive Maximum Load Current, 5, 10 hp Coil, 3 Pole, Double Break Contact, Quick-Connect (Side by Side) Connection, Pressure Plate/Screw Terminal, Open Enclosure, 300000 Cycles Operating Cycles, 150 deg F Operating, Surface Mounting, 3.35 in L x 2.4 in W x 3.75 in H Dimensions

Specifications

 Application Heating, Ventilation, Air Conditioning, Refrigeration (HVACR), Motor and Power Control Equipment
 Brand Name EATON
 Coil Power Rating 5, 10 hp
 Coil Voltage 208 to 240 V AC at 50/60 Hz
 Connection Type Quick-Connect (Side by Side)
 Contact Type Double Break
 Dimensions 3.35 in L x 2.4 in W x 3.75 in H
 Enclosure Open
 Manufacturer Part Number C25DND330B
 Maximum Load Current 30 A Inductive/40 A Resistive
 Mounting Type Surface
 Number of Poles 3
 Operating Cycles 300000 Cycles
 Operating Temperature 150 deg F
 PART NUMBER KEYWORDS C25DND330B ; 7406283 ; 782116300617 ; 78211630061 ; 00782116300617
 Standards/Approvals UL Recognized,CSA Certified,RoHS Compliant
 Terminal Type Pressure Plate/Screw
 Type D-Frame Non-Reversing

Features

▪ The universal mounting plate eliminates changing hole patterns when replacing competitive devices
▪ Variety of terminal styles allows product to meet all specific application needs
▪ Snap-on accessories require no tools for hassle-free installation
▪ Quick coil changing ability allows for easy maintenance
▪ Non-position sensitive mounting allows for fast, convenient setup
▪ Shrouded or fingerproof terminals to reduce possibility of electrical shock
▪ 5 hp at 1 ph, 10 hp at 3 ph motor rating
▪ 15 to 50 A frame
