Eaton
BK/GMT-1A BUSS INDICATING FUSE FAST ACTING 05171257690

Mouse over image to zoom, click to enlarge

  • BK/GMT-1A BUSS INDICATING FUSE FAST ACTING 05171257690
  • BK/GMT-1A BUSS INDICATING FUSE FAST ACTING 05171257690
  • BK/GMT-1A BUSS INDICATING FUSE FAST ACTING 05171257690
  • BK/GMT-1A BUSS INDICATING FUSE FAST ACTING 05171257690

Description: Bussmann Telecommunication Fuse, Fast Acting, Series: GMT, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 1 A, 125 VAC/60 VDC, 300 A at 125 VAC, 450 A at 60 VDC Interrupt, 10 min at 100%/5 min at 150% Response, Quick-Connect Terminal, Snap-In Mount, Flat Body, Single Element, Thermoplastic, Gray, 0.81 in L x 0.688 in H Body Size

Manufacturer PN: BK/GMT-1A

UPC:  05171257690

Kendall Electric Inc PN: 2457798

Invoice Description:

BK/GMT-1A BUSS INDICATING FUSE FAST ACTING 05171257690


SPEC SHEET

▸ See All in Alarm Indicating Fuses


How Can We Make This Page Better?

Bussmann BK/GMT-1A Fast Acting Telecommunication Fuse, 1 A, 125 VAC/60 VDC, 300 A at 125 VAC, 450 A at 60 VDC Interrupt, Flat Body

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Bussmann Telecommunication Fuse, Fast Acting, Series: GMT, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 1 A, 125 VAC/60 VDC, 300 A at 125 VAC, 450 A at 60 VDC Interrupt, 10 min at 100%/5 min at 150% Response, Quick-Connect Terminal, Snap-In Mount, Flat Body, Single Element, Thermoplastic, Gray, 0.81 in L x 0.688 in H Body Size

Specifications

 Amperage Rating 1 A
 Application IT and Data Communication, Telecommunication DC Power Circuit Protection and for use in HLT, HLS and PCT Fuse Holders and Other Applications
 Body Size 0.81 in L x 0.688 in H
 Body Type Flat
 Brand Name Bussmann
 Color Gray
 Element Single
 Indicating Non Indicating Non-Indicating
 Manufacturer Part Number BK/GMT-1A
 Material Thermoplastic
 Mounting Type Snap-In
 Rejection Non Rejection Non-Rejection
 Response Time 10 min at 100%/5 min at 150%
 Series GMT
 Standards/Approvals CE Certified|RoHS Compliant|UL 94-V-0 Flammability Rating|UL Listed Guide JFHR2, File No. E56412
 Terminal Type Quick-Connect
 Type Fast Acting
 Video Links
 Voltage Rating 125 VAC/60 VDC

Features

▪ Local and remote indication capability
▪ Color coded for easy amp rating identification
▪ Visual spring indicating and alarm circuit indicating
▪ Fuses easily replaced without use of insulated tools
▪ Fuses can be removed with wire hook when mounted on minimum centers
▪ Tin plated beryllium copper terminal
