BIBS3503DB BURNDY 350-12 DB UNITAP 3 PORT 78181052359

Mouse over image to zoom, click to enlarge

Description: BURNDY® UNITAP™ Connector, 3-Port Type BIBS, Aluminum/Copper/Stranded Conductor, 12 AWG to 350 kcmil Run/Main, 600 V AC, 450 in-lb Installation Torque, 1-1/8 in L Wire Strip, 194 deg F, Aluminum, Unplated/Clear, 3.82 in L x 46 in W x 2.46 in H

Manufacturer PN: BIBS3503DB

UPC:  78181052359

Kendall Electric Inc PN: 2869715

Invoice Description:

BIBS3503DB BURNDY 350-12 DB UNITAP 3 PORT 78181052359


SPEC SHEET

▸ See All in Mechanical Multiple Cable Taps


How Can We Make This Page Better?

BURNDY® UNITAP™ BIBS3503DB 3-Port Type BIBS Connector, Aluminum/Copper/Stranded Conductor, 12 AWG to 350 kcmil Run/Main, Aluminum

Log In for Pricing and Availability




Description

Direct Burial UNITAPâ, 350 Kcmil -12 AWG Str., 3.82 in L, Designed specifically for direct burial applications.
BURNDY® UNITAP™ Connector, 3-Port Type BIBS, Aluminum/Copper/Stranded Conductor, 12 AWG to 350 kcmil Run/Main, 600 V AC, 450 in-lb Installation Torque, 1-1/8 in L Wire Strip, 194 deg F, Aluminum, Unplated/Clear, 3.82 in L x 46 in W x 2.46 in H

Specifications

 Application Wet, Damp Locations and Outside Direct Burial Applications
 Brand Name BURNDY
 Conductor Type Aluminum/Copper/Stranded
 Dimensions 3.82 in L x 46 in W x 2.46 in H
 Finish Unplated/Clear
 Manufacturer Part Number BIBS3503DB
 Material Aluminum
 PART NUMBER KEYWORDS BIBS3503DB ; 11270347 ; 781810523599 ; 78181052359 ; 00781810523599
 Run Main Size 12 AWG to 350 kcmil
 Specifications 450 in-lb Installation Torque, 1-1/8 in L Wire Strip
 Standards/Approvals ARRA Compliant|BAA Compliant|CSA Certified|RoHS Compliant|UL Listed|PROP65: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov|Buy American Act Compliant
 Temperature Rating 194 deg F
 Type 3-Port Type BIBS
 Voltage Rating 600 V AC

Features

▪ Dual rated for aluminum or copper conductors
▪ Each unit individually marked for ease of identification
▪ Supplied with aluminum set-screws
▪ Supplied with oxide inhibitor pre-installed
▪ Submersible rated and suitable for Direct Burial
