BG806L STEEL CITY 2 GND BUSHING RGD/IMC DC ZINC INS..

Mouse over image to zoom, click to enlarge

  • BG806L STEEL CITY 2 GND BUSHING RGD/IMC DC ZINC INS..
  • BG806L STEEL CITY 2 GND BUSHING RGD/IMC DC ZINC INS..
  • BG806L STEEL CITY 2 GND BUSHING RGD/IMC DC ZINC INS..
  • BG806L STEEL CITY 2 GND BUSHING RGD/IMC DC ZINC INS..
  • BG806L STEEL CITY 2 GND BUSHING RGD/IMC DC ZINC INS..

Description: Steel City® Grounding Bushing, Insulated, Series: BG Series, 2 in Trade, 14 AWG Minimum Wire, 2 AWG Maximum Wire, 48.9 mm Throat, Lay-In Lug, 67.8 mm Diameter, 35 mm Height, Die Cast Zinc

Manufacturer PN: BG806L

UPC:  78599108868

Kendall Electric Inc PN: 4367067

Invoice Description:

BG806L STEEL CITY 2 GND BUSHING RGD/IMC DC ZINC INS..


SPEC SHEET

▸ See All in Ground Bushings


How Can We Make This Page Better?

Steel City® BG806L Insulated Grounding Bushing With Aluminum Lug, 2 in Trade, 14 AWG Wire Min, 2 AWG Wire Max, 67.8 mm Dia, Die Cast Zinc

Log In for Pricing and Availability




Description

Steel City® products have set the standard as the leading brand in electrical construction. In manufacturing quality and innovative design, Steel City® has no peer.
Steel City® Grounding Bushing, Insulated, Series: BG Series, 2 in Trade, 14 AWG Minimum Wire, 2 AWG Maximum Wire, 48.9 mm Throat, Lay-In Lug, 67.8 mm Diameter, 35 mm Height, Die Cast Zinc

Specifications

 Application Rigid/IMC Conduit
 Brand Name Steel City
 Height 35 mm
 Lug Type Lay-In
 Manufacturer Part Number BG806L
 Material Die Cast Zinc
 Maximum Wire Size 2 AWG
 Minimum Wire Size 14 AWG
 PART NUMBER KEYWORDS BG806L ; 7TAA117110R0015 ; 13215624 ; 785991088687 ; 78599108868 ; 00785991088687
 Series BG Series
 Standards/Approvals UL File No. E3060|cULus Listed
 Throat 48.9 mm
 Trade Size 2 in
 Type Insulated

Features

▪ Features thermoplastic liners for 105 deg C
▪ Threaded design with heavy reinforced ribs
