Part # 2880395

instructions how to enable JavaScript in your web browser

Page Loading...

Eaton

Mouse over image to zoom, click to enlarge

Description: EATON Bussmann Busbar, 6-Pin Single Phase Non-Indicating Modular Combo Class J, 1 kV DC, 100 A

Manufacturer PN: BB1P100M6

UPC: 05171236598

Kendall Electric Inc PN: 2880395

Invoice Description:

BB1P100M6 BUSS SNGL-PHASE 1000V DC BB 100A 6 PINS EC 05171236598

SPEC SHEET

EATON Bussmann BB1P100M6 6-Pin Single Phase Non-Indicating Modular Combo Class J Busbar With Assembled End Cap, 1 kV DC

Description Specifications Features Resources

EATON Bussmann Busbar, 6-Pin Single Phase Non-Indicating Modular Combo Class J, 1 kV DC, 100 A

Amperage Rating	100 A
Application	Electrical Assemblies, Panels and EOEMs Applications
Brand Name	Bussmann
Manufacturer Part Number	BB1P100M6
PART NUMBER KEYWORDS	BB1P100M6 ; 11278956 ; 051712365987 ; 51712365987 ; 05171236598 ; 00051712365987
Standards/Approvals	RoHS Compliant\|UL 508 File No. E195399
Type	6-Pin Single Phase Non-Indicating Modular Combo Class J
Video Links
Voltage Rating	1 kV DC

▪ Flexible cut to length solutions without compromising on the product's finger safe features

▪ 100 kA short circuit current rating when protected by a 200 A class J fuse

▪ 1 ph bus bars rated to 1000 VDC and 100 A in end fed configuration

▪ Power feed terminals for 1 ph systems
