Eaton
B141ZN B-LINE THREE HOLE SPLICE PLATE ZINC PLATED..

Mouse over image to zoom, click to enlarge

Description: B-Line Splice Plate, Flat, 3 Holes, 5-3/8 in Length, 1-5/8 in Width, 1/4 in Thickness, 9/16 in Dia Hole, 1-7/8 in Hole Spacing, Strip Steel, Zinc Plated

Manufacturer PN: B141ZN

UPC:  78101150443

Kendall Electric Inc PN: 2614704

Invoice Description:

B141ZN B-LINE THREE HOLE SPLICE PLATE ZINC PLATED..


SPEC SHEET

▸ See All in Channel Flat Plate Fittings


How Can We Make This Page Better?

B-Line B141ZN Flat Splice Plate, 3 Holes, 5-3/8 in L x 1-5/8 in W x 1/4 in THK, Strip Steel

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

B-Line series strut fitting complete the full line of our strut system and include many time and material saving solutions. These accessories are available in a variety of materials, finishes and configurations to work with B-Line series strut channel
B-Line Splice Plate, Flat, 3 Holes, 5-3/8 in Length, 1-5/8 in Width, 1/4 in Thickness, 9/16 in Dia Hole, 1-7/8 in Hole Spacing, Strip Steel, Zinc Plated

Specifications

 Application Strut Systems/Bolted Framing and Flat Plate
 Brand Name B-Line
 Finish Zinc Plated
 Hole Size 9/16 in Dia
 Hole Spacing 1-7/8 in
 Includes Steel
 Length 5-3/8 in
 Manufacturer Part Number B141ZN
 Material Strip Steel
 Number of Holes 3
 PART NUMBER KEYWORDS B141ZN ; 78101150443 ; 8211385 ; 781011504434 ; 78101150443 ; 00781011504434
 Type Flat
 Width 1-5/8 in

Features

▪ Fittings are made from hot rolled, pickled and oiled plate or strip steel in accordance with ASTM A1018 33000 psi minimum yield, unless noted
▪ Combination design reduces the number of parts to handle and purchase
▪ Allows for easy adjustment when installed in channel
▪ Channel nuts and bolts have locking liquid applied
▪ No worry of spring protruding through bottom of slotted channel
▪ Reduces installation time
▪ No more tangled spring nuts

Resources

 Catalog
 Catalog Page
 Product Data Sheet
