Schneider Electric
  • ATV12H037F1 SQD AC DRIVE 0.5 HP
  • ATV12H037F1 SQD AC DRIVE 0.5 HP
  • ATV12H037F1 SQD AC DRIVE 0.5 HP
  • ATV12H037F1 SQD AC DRIVE 0.5 HP
  • ATV12H037F1 SQD AC DRIVE 0.5 HP

Description: Schneider Electric Altivar™ 12 Square D™ Variable Speed Drive, 1-Phase, 100 to 120/115 VAC, 2.4 A, 0.55 hp, 2.83 in Width, 4.77 in Depth, 5.63 in Height, IP20/Open Enclosure, LED Display, Panel Mounting

Manufacturer PN: ATV12H037F1

UPC:  60648007102

Kendall Electric Inc PN: 4004986

Invoice Description:

ATV12H037F1 SQD AC DRIVE 0.5 HP


SPEC SHEET

▸ See All in Variable Frequency Drives


How Can We Make This Page Better?

Schneider Electric Altivar™ 12 Square D™ ATV12H037F1 1-Phase Variable Speed Drive With Heat Sink, 100 to 120/115 VAC, 2.4 A, 0.55 hp, 2.83 in W x 4.77 in D

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

This variable speed / frequency drive (VSD / VFD) is designed for simple industry and commercial machines and appliances, such as conveyors, pumps, extractors, access barriers and treadmills. Its slim footprint allows for mounting within frames of simple non-industrial appliances. It can be configured before while still in its packaging without even using a power supply, thus minimizing installation time. SoMove software compatibility enables saving and transferring of configurations to spare drive, reducing maintenance downtime.
Schneider Electric Altivar™ 12 Square D™ Variable Speed Drive, 1-Phase, 100 to 120/115 VAC, 2.4 A, 0.55 hp, 2.83 in Width, 4.77 in Depth, 5.63 in Height, IP20/Open Enclosure, LED Display, Panel Mounting

Specifications

 Amperage Rating 2.4 A
 Application Simple Machines, Conveyors, Food and Beverage, Gate Control, HVAC, Machine Movement, Mixers and Packaging Applications
 Brand Name Square D
 Depth 4.77 in
 Enclosure IP20/Open
 Height 5.63 in
 Horsepower 0.55 hp
 Manufacturer Part Number ATV12H037F1
 Mounting Type Panel
 Standards/Approvals C-Tick Compliant|CE Certified|CSA Certified|ECCN EAR99|EN/IEC 60068-2-6/60068-2-27/61800-3 2, 4, 8, 12/61000-4-6/60068-2-6-1/60721-3-3/61000-4-5|GOST Certified|NOM Certified|PROP65: This product can expose you to chemicals including: Lead and Lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov|RoHS Compliant|UL Listed
 Type 1-Phase
 Video Links
 Voltage Rating 100 to 120/115 VAC
 Width 2.83 in

Features

▪ Designed for easy fitting and wiring of the drive
▪ Save time on wiring, commissioning and programming
▪ Discreet in size but big on performance
▪ Simple to use manual controls for testing or local operation
▪ Flexible design
▪ Superior motor control
▪ -10 to 60 deg C operating temperature
