Description: Square D™ Altistart® 22 Soft Starter, Internal Bypass, Series: ATS22, 208/600 V AC, 170 A, 50/60 Hz, 50 hp, 60 hp, 125 hp, 150 hp Motor, 110 VAC Coil, 3 ph, RJ45, IP00, 104 to 140 deg F Operating, 5.91 in W x 9.04 in D x 14.02 in H

Manufacturer PN: ATS22C17S6U

UPC:  60648016745

Kendall Electric Inc PN: 3962286

Invoice Description:

ATS22C17S6U SQD SOFT START


SPEC SHEET

▸ See All in Open Soft Starters


How Can We Make This Page Better?

Square D™ Altistart® 22 ATS22C17S6U Internal Bypass Soft Starter, 110 VAC V Coil, IP00 Enclosure

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

This Altistart 22 soft starter can feed 3-phase asynchronous motors in supply line connection. It has a rating of 170A, a rated power from 50HP to 150HP and a rated voltage from 230V to 575V AC. It is designed for simple and complex machines such as centrifugal and piston pumps, fans, screw compressors and material handling equipment. Slim form factor improves versatility; allows mounting in frames of any kind of machines. It features an Integrated bypass, this reduces noise and decreases heat dissipation. Compatibility with SoMove software allows configurations and settings to be easily transferred, meaning spares can be quickly installed. It provides smooth starting for your machinery, avoiding mechanical stresses and extending their service life.
Square D™ Altistart® 22 Soft Starter, Internal Bypass, Series: ATS22, 208/600 V AC, 170 A, 50/60 Hz, 50 hp, 60 hp, 125 hp, 150 hp Motor, 110 VAC Coil, 3 ph, RJ45, IP00, 104 to 140 deg F Operating, 5.91 in W x 9.04 in D x 14.02 in H

Specifications

 Amperage Rating 170 A
 Application Asynchronous Motors, Centrifugal Pumps, Piston Pumps, Fans, Screw Compressors, Material Handling Conveyors and Specialist Machinery Applications
 Brand Name Square D
 Coil Voltage 110 V AC
 Connection Type RJ45
 Dimensions 5.91 in W x 9.04 in D x 14.02 in H
 Enclosure IP00
 Frequency Rating 50/60 Hz
 Manufacturer Part Number ATS22C17S6U
 Motor Power 50 hp, 60 hp, 125 hp, 150 hp
 Operating Temperature 104 to 140 deg F
 Phase 3
 Series ATS22
 Standards/Approvals IP00
 Type Internal Bypass
 Voltage Rating 208/600 V AC

Features

▪ This Schneider Electric Altistart 22 soft-starter can feed 3-phase asynchronous motors in supply line connection with a rating of 170 amperes, a rated power from 50 to 150 horsepower and a rated voltage from 230 to 575Vac
