Description: Hubbell Wiring Device-Kellems H-MOSS® Occupancy Sensor, Adaptive Dual Technology, Series: ATD, 24 V DC, 33 mA, Passive Infrared/Ultrasonic Sensor, 2000 sq-ft Coverage, 360 deg Viewing, 8 to 40 min Adaptive, 8 s Test Delay, LED Lamp, 32 kHz Response, Wire Lead, 32 to 104 deg F, ABS, White, 4-1/2 in Dia x 1-1/2 in D

Manufacturer PN: ATD2000C

UPC:  78358539243

Kendall Electric Inc PN: 2205213

Invoice Description:

ATD2000C KELLEMS HMOSS ADAPTIVE TECH/DUAL CEILING SENSOR 78358539243..


SPEC SHEET

▸ See All in Ceiling Mount Occupancy Sensors


How Can We Make This Page Better?

Hubbell Wiring Device-Kellems H-MOSS® ATD2000C Adaptive Dual Technology Occupancy Sensor, 24 V DC, Passive Infrared/Ultrasonic Sensor, 2000 sq-ft Coverage, 360 deg Viewing

Log In for Pricing and Availability




Description

Dual technology occupancy sensors combine both passive infrared (PIR) and ultrasonic (US) technologies for maximum reliability. Because US and PIR need to both detect occupancy to turn lighting on, dual technology sensors minimize the risk of lights coming on when the space is unoccupied false triggering. Continued detection by only one technology then keeps lighting on as necessary. Dual technology sensors offer the best performance for most applications.
Hubbell Wiring Device-Kellems H-MOSS® Occupancy Sensor, Adaptive Dual Technology, Series: ATD, 24 V DC, 33 mA, Passive Infrared/Ultrasonic Sensor, 2000 sq-ft Coverage, 360 deg Viewing, 8 to 40 min Adaptive, 8 s Test Delay, LED Lamp, 32 kHz Response, Wire Lead, 32 to 104 deg F, ABS, White, 4-1/2 in Dia x 1-1/2 in D

Specifications

 Amperage Rating 33 mA
 Application Office, Conference Room, Classroom, Hall and Indoor Dry Environment Applications
 Brand Name Hubbell Premise Wiring
 Color White
 Connection Type Wire Lead
 Coverage 2000 sq-ft
 Dimensions 4-1/2 in Dia x 1-1/2 in D
 Lamp Type LED
 Manufacturer Part Number ATD2000C
 Material ABS
 Response Frequency 32 kHz
 Sensor Type Passive Infrared/Ultrasonic
 Series ATD
 Standards/Approvals ASHRAE 90.1|CEC Title 24 Certified|cULus Listed|RoHS Compliant|UL 244A|UL 94 V-0 Flammability Rated
 Temperature Rating 32 to 104 deg F
 Time Delay 8 to 40 min Adaptive, 8 s Test
 Type Adaptive Dual Technology
 Video Links
 Viewing Angle 360 deg
 Voltage Rating 24 V DC

Features

▪ Minimize the risk of false triggering
▪ lights turning ON when the space is un-occupied
▪ Office White ABS enclosure blends with ceiling tile
▪ Install and Forget operation
▪ Auto-adjusting adaptive technology eliminates manual adjustments
