Broan-NuTone
AE50-110DCL BROAN FLEX DC EXHAUST FAN 50-80-110CFM

Mouse over image to zoom, click to enlarge

  • AE50-110DCL BROAN FLEX DC EXHAUST FAN 50-80-110CFM
  • AE50-110DCL BROAN FLEX DC EXHAUST FAN 50-80-110CFM

Description: Broan® Bathroom Exhaust Fan, Series: Flex DC™ Series, 120 V, 0.4 A, LED Lamp, 11 W Lamp, 1 Lamps, 25000 hr Average Life, Soft White Light, 3500 K Color Temperature, Ceiling Mounting, 3 Fan Speed Control, 50 to 110 cfm Air Flow, 3.4 to 14.9 W Fan Motor Wattage, 26 ga Galvanized Steel Housing Material, 9-1/4 in L x 10 in W x 5-3/4 in H Dimensions

Manufacturer PN: AE50110DCL

UPC:  02671525699

Kendall Electric Inc PN: 3907341

Invoice Description:

AE50-110DCL BROAN FLEX DC EXHAUST FAN 50-80-110CFM


SPEC SHEET

▸ See All in Bathroom Exhaust Fans


How Can We Make This Page Better?

Broan® AE50110DCL Flex DC™ Series Bathroom Exhaust Fan With LED Light, Brushless DC Motor, (1) LED Lamp, 120 V, 26 ga Galvanized Steel Housing

Log In for Pricing and Availability




Description

Broan® AE50110DCL Flex DC™ Series Exhaust Bath Fan with LED, ENERGY STAR® offers easy, room side installation, with "No Attic Access Required". Ceiling mounted ventilation fan features foldable mounting ears and EZ Duct connector for easy installation. New duct damper technology provides a tighter seal, resulting in reduced warm and cold air backdrafts. This energy efficient fan operates at a selectable CFM range of 50/80/110 at a quiet operation of <0.3-0.4-0.9 sones.
Broan® Bathroom Exhaust Fan, Series: Flex DC™ Series, 120 V, 0.4 A, LED Lamp, 11 W Lamp, 1 Lamps, 25000 hr Average Life, Soft White Light, 3500 K Color Temperature, Ceiling Mounting, 3 Fan Speed Control, 50 to 110 cfm Air Flow, 3.4 to 14.9 W Fan Motor Wattage, 26 ga Galvanized Steel Housing Material, 9-1/4 in L x 10 in W x 5-3/4 in H Dimensions

Specifications

 Air Flow Rate 50 to 110 cfm
 Amperage Rating 0.4 A
 Average Life 25000 hr
 Brand Name Broan
 Color Temperature 3500 K
 Dimensions 9-1/4 in L x 10 in W x 5-3/4 in H
 Fan Motor Wattage 3.4 to 14.9 W
 Fan Speed Control 3
 Housing Material 26 ga Galvanized Steel
 Lamp Type LED
 Lamp Wattage 11 W
 Light Color Soft White
 Manufacturer Part Number AE50110DCL
 Mounting Type Ceiling
 Number of Lamps 1
 Series Flex DC™ Series
 Standards/Approvals cULus Listed|ENERGY STAR Certified|HVI 2100 Certified
 Video Links
 Voltage Rating 120 V

Features

▪ UL Listed for use over tubs and showers with a GFCI circuit; so you can capture the steam before it spreads throughout the room by locating your fan exactly where you need it the most
▪ Quiet, energy efficient exhaust fan to help control air quality
▪ Selectable CFM For flexible installation
▪ Easy to install new/replace existing product from the roomside
▪ FlexFlow™ technology, select between 50, 80 or 110 cfm
▪ Quiet operation at <0.3/0.4/0.9 sones
▪ Powerful ventilation reduces humidity to quickly eliminate fogged mirrors and manage moisture, so your vision will always be clear and your surroundings will always be comfortable
▪ Retrofit installations can be done entirely from the room-side - no attic access required
▪ This means a faster, easier installation, so you can move on to something else
▪ Flex DC™ fans reduce air leakage by up to 50% compared to competitive models, resulting in better home performance via blower door tests and reducing cold and warm air backdrafts
▪ Plug in, permanently lubricated, brushless DC motor - engineered for continuous operation
▪ Can be installed in a wall if mounted 8 ft or more above the floor
▪ Includes an 11 W, 3500 K, integrated LED module that lasts up to 25000 hr for maintenance-free convenience
