Part # 21105

instructions how to enable JavaScript in your web browser

Page Loading...

Eaton

Mouse over image to zoom, click to enlarge

Description: Bussmann Fusetron™ Time Delay Fuse, Low Voltage, Series: ACK, 150 A, 72 V DC, 10 kA Interrupt, 100 S at 200%, 35 S 300%, 13 S at 500% Response, Stud Mount, Dual Element, Copper, 1.062 in Dia x 3.75 in L Body Size

Manufacturer PN: ACK-150

UPC: 05171270141

Kendall Electric Inc PN: 21105

Invoice Description:

ACK150 BUS 125V TD STUD MTD FUSE

SPEC SHEET

How Can We Make This Page Better?

Bussmann Fusetron™ ACK-150 Low Voltage Time Delay Fuse, 150 A, 72 V DC, 10 kA Interrupt

Note: Lead times are estimates only

Description Specifications Features Resources

Description

Bussmann Fusetron™ Time Delay Fuse, Low Voltage, Series: ACK, 150 A, 72 V DC, 10 kA Interrupt, 100 S at 200%, 35 S 300%, 13 S at 500% Response, Stud Mount, Dual Element, Copper, 1.062 in Dia x 3.75 in L Body Size

Specifications

Amperage Rating	150 A
Application	Forklift trucks, battery hand trucks, motorized work platforms and battery systems applications, safety and security systems
Body Size	1.062 in Dia x 3.75 in L
Brand Name	Bussmann
Element	Dual
Manufacturer Part Number	ACK-150
Material	Copper
Mounting Type	Stud
PART NUMBER KEYWORDS	ACK-150 ; ACK150 ; 7636425 ; 051712701419 ; 51712701419 ; 05171270141 ; 00051712701419 ; 5027590425650
Response Time	100 S at 200%, 35 S 300%, 13 S at 500%
Series	ACK
Standards/Approvals	UL Listed
Type	Low Voltage
Video Links
Voltage Rating	72 V DC

Features

▪ A fuse link which operates only on very high overloads or short circuits

▪ Thermal cutout functions on low overloads, the thermal cutout cannot operate quickly at any load, hence long time lag is obtained on high overloads of short duration

▪ This long time lag also makes it unnecessary to use extra large size or over size fuses
