Eaton
A201K2BA CH A201 - CONTACTOR, SIZE 2, OPEN, 2 POLE, 120V / 60HZ COIL

Mouse over image to zoom, click to enlarge

  • A201K2BA CH A201 - CONTACTOR, SIZE 2, OPEN, 2 POLE, 120V / 60HZ COIL
  • A201K2BA CH A201 - CONTACTOR, SIZE 2, OPEN, 2 POLE, 120V / 60HZ COIL
  • A201K2BA CH A201 - CONTACTOR, SIZE 2, OPEN, 2 POLE, 120V / 60HZ COIL

Description: EATON NEMA Contactor, Full Voltage Non-Reversing, Series: A200, 110/120 V AC Coil, 45 A Maximum Load Current, 2 Pole, 50/60 Hz Frequency, 1NO Contact Configuration, 1 Auxiliary Contacts, Front Connection, SZ 2 Size, Open Enclosure, Surface Mounting, 4.94 in L x 4.38 in W x 3.31 in H Dimensions

Manufacturer PN: A201K2BA

UPC:  78667823159

Kendall Electric Inc PN: 3720742

Invoice Description:

A201K2BA CH A201 - CONTACTOR, SIZE 2, OPEN, 2 POLE, 120V / 60HZ COIL


SPEC SHEET

▸ See All in NEMA & IEC Contactors


How Can We Make This Page Better?

EATON A201K2BA Full Voltage Non-Reversing NEMA Contactor, 110/120 V AC V Coil, 45 A, 1NO Contact, 2 Poles

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

All Class A200 non-reversing starters utilize Type B three-pole overload relays with optional Type A for auto reset applications. Sizes 5 and 6 include the needed current transformers. Moving and stationary contacts are front accessible for simple and easy inspection and maintenance. All Class A200 starters are UL listed and recognized and are CSA certified.
EATON NEMA Contactor, Full Voltage Non-Reversing, Series: A200, 110/120 V AC Coil, 45 A Maximum Load Current, 2 Pole, 50/60 Hz Frequency, 1NO Contact Configuration, 1 Auxiliary Contacts, Front Connection, SZ 2 Size, Open Enclosure, Surface Mounting, 4.94 in L x 4.38 in W x 3.31 in H Dimensions

Specifications

 Application Electrical Assemblies, Panels and EOEMs Applications
 Brand Name EATON
 Coil Voltage 110/120 V AC
 Connection Type Front
 Contact Configuration 1NO
 Dimensions 4.94 in L x 4.38 in W x 3.31 in H
 Enclosure Open
 Frequency Rating 50/60 Hz
 Manufacturer Part Number A201K2BA
 Maximum Load Current 45 A
 Mounting Type Surface
 Number of Auxiliary Contacts 1
 Number of Poles 2
 PART NUMBER KEYWORDS A201K2BA ; 7444715 ; 786678231594 ; 78667823159 ; 00786678231594
 Series A200
 Size SZ 2
 Standards/Approvals UL Listed,CSA Certified
 Type Full Voltage Non-Reversing

Features

▪ Electronic coil controller allows contactors to reduce power consumption and generate less heat, resulting in lower cooling requirements, the ability to mount more contactors/starters per cabinet and an extended life on pilot devices that carry control signals
▪ AC and DC devices with the same dimensions achieved with an electronically controlled coil system allow for space savings and reduced engineering design time
▪ Integrated suppressors in DC controlled contactors offers reductions in total logistics and inventory costs by limiting the number of products ordered and stocked
▪ Wiring is not required, therefore increasing installation and maintenance efficiency
▪ Expanded range of DC coil control voltages, allows reliable operation through fluctuations in control voltages
▪ Twin terminals with separate sockets in contactors up to 400 A offer installation and application flexibility when using different size wires
▪ The improved integrity of the connections reduces cabling faults
▪ 3 hp at 115 VAC, 7.5 hp at 230 VAC 1 ph, 10 hp at 208 VAC, 15 hp at 240 VAC, 25 hp at 480 VAC and 25 hp at 600 VAC 3 ph power rating
