9036DG2R-SQD SQD FLOAT SWITCH 575VAC ZZZZ

Mouse over image to zoom, click to enlarge

Description: Telemecanique Float Switch, Type D Reverse, Series: 9036, 575 V AC, 20 A, 3.7 kW Wattage, Screw Clamp Connection, NEMA 1 Enclosure, -22 to 220 deg F Operating, Surface Mounting

Manufacturer PN: 9036DG2R-SQD

Kendall Electric Inc PN: 4048058

Invoice Description:

9036DG2R-SQD SQD FLOAT SWITCH 575VAC ZZZZ


SPEC SHEET

▸ See All in Liquid Level Sensors/Float Switches


How Can We Make This Page Better?

Telemecanique 9036DG2R Type D Reverse Float Switch, 575 V AC

Log In for Pricing and Availability

Note: Lead times are estimates only




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

Telemecanique Float Switch, Type D Reverse, Series: 9036, 575 V AC, 20 A, 3.7 kW Wattage, Screw Clamp Connection, NEMA 1 Enclosure, -22 to 220 deg F Operating, Surface Mounting

Specifications

 Amperage Rating 20 A
 Application Open Tank or Sump Applications and Liquid Level Control
 Brand Name Square D
 Connection Type Screw Clamp
 Enclosure NEMA 1
 Manufacturer Part Number 9036DG2R
 Mounting Type Surface
 Operating Temperature -22 to 220 deg F
 PART NUMBER KEYWORDS 9036DG2R ; 8100805 ; 785901576433 ; 78590157643 ; 00785901576433 ; 0785901576433
 Series 9036
 Standards/Approvals RoHS Compliant|UL 508 E12158|CSA LR25490|CE Marked|PPROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
 Type Type D Reverse
 Voltage Rating 575 V AC
 Wattage 3.7 kW

Features

▪ Variable adjustable float movement
▪ 20 A by cartridge fuse, type gG short circuit protection
▪ 2 NO DPST-DB contact configuration
▪ 1/2 in NPT conduit entrance cable entry
▪ 10 AWG wire
▪ Vertical float rod angle
▪ 1-1/4 in float travel
▪ 7 in Dia x 7 in L float dimension
▪ Polypropylene enclosure material
▪ Indoor enclosure
▪ 3.7 kW at 230 VAC 3-ph electrical rating
