WAGO Corporation
859-802 WAGO 51228934 DC/DCIN DC 24V, GRAY

Mouse over image to zoom, click to enlarge

Description: WAGO DC to DC Converter, 15 to 30 V DC Input, 10 VDC Output, 500 mA Output, Carrier Rail 35 x 15 Mount, -25 to 55 deg C, 0.236 in W x 3.583 in D, Gray

Manufacturer PN: 859-802

UPC:  05082108331

Kendall Electric Inc PN: 3974948

Invoice Description:

859-802 WAGO 51228934 DC/DCIN DC 24V, GRAY


SPEC SHEET

▸ See All in DC to DC Converters


How Can We Make This Page Better?

WAGO 859-802 DC to DC Converter, 15 to 30 V DC Input, 10 VDC Output, 500 mA Output

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

WAGO DC to DC Converter, 15 to 30 V DC Input, 10 VDC Output, 500 mA Output, Carrier Rail 35 x 15 Mount, -25 to 55 deg C, 0.236 in W x 3.583 in D, Gray

Specifications

 Brand Name WAGO
 Color Gray
 Input Voltage 15 to 30 V DC
 Manufacturer Part Number 859-802
 Mounting Type Carrier Rail 35 x 15
 Output Amperage 500 mA
 Output Voltage 10 V DC
 PART NUMBER KEYWORDS 859-802 ; 859802 ; 4050821083313
 Size 0.236 in W x 3.583 in D
 Standards/Approvals RoHS Compliant
 Temperature Rating -25 to 55 deg C

Features

▪ 85% efficiency full load at 24 VDC
▪ 5 connection points
▪ Cage Clamp® connection technology
▪ 28 to 14 AWG solid conductor
▪ 5 to 6 mm strip length
▪ 2.205 in height from upper-edge of Din-35 rail
▪ Front-entry wiring
▪ 5-potentials
▪ 100 ppm/deg C temperature coefficient
▪ Non-isolated
▪ 0.7% maximum load regulation
▪ 0.5% maximum line regulation
▪ 500 usec maximum transient recovery time
▪ 500 usec maximum hold time
▪ 200 kHz switching frequency
