WAGO Corporation
859-801 WAGO 51225851 DC/DCIN DC 24V, GRAY

Mouse over image to zoom, click to enlarge

Description: WAGO DC to DC Converter, Non-Isolated, 10 to 30 V DC Input, 2 VDC Output, 0.5 A Input, Carrier Rail 35 x 15 Mount, 0.236 in W x 3.583 in D, Gray

Manufacturer PN: 859-801

UPC:  05082102156

Kendall Electric Inc PN: 4002669

Invoice Description:

859-801 WAGO 51225851 DC/DCIN DC 24V, GRAY


SPEC SHEET

▸ See All in DC to DC Converters


How Can We Make This Page Better?

WAGO 859-801 Non-Isolated DC to DC Converter, 10 to 30 V DC Input, 2 VDC Output, 0.5 A Input

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

WAGO DC to DC Converter, Non-Isolated, 10 to 30 V DC Input, 2 VDC Output, 0.5 A Input, Carrier Rail 35 x 15 Mount, 0.236 in W x 3.583 in D, Gray

Specifications

 Brand Name WAGO
 Color Gray
 Input Amperage 0.5 A
 Input Voltage 10 to 30 V DC
 Manufacturer Part Number 859-801
 Mounting Type Carrier Rail 35 x 15
 Output Voltage 2 V DC
 PART NUMBER KEYWORDS 859-801 ; 859801 ; 4050821021568
 Size 0.236 in W x 3.583 in D
 Standards/Approvals RoHS Compliant
 Type Non-Isolated

Features

▪ 500 mA single, 10 mm spacing, 400 mA assembly output current
▪ 150 mV output noise peak-to-peak max
▪ 5 connection point
▪ Cage Clamp® connection technology
▪ 14 to 28 AWG solid conductor
▪ 0.2 to 0.24 strip length
▪ 2.205 in height from upper-edge of Din-35 rail
▪ 0.582 MJ fire load
▪ Front-entry wiring
▪ 5-potentials
▪ 70 ppm deg C temperature coefficient
▪ 0.5% maximum load regulation, 2% maximum line regulation
▪ 40 usec maximum transient recovery time
▪ 1 msec maximum hold time
▪ 200 kHz nominal switching frequency
▪ 70% efficiency at full load
▪ TVS diode input fuse
