nVent
812M CDY 1/2 TO 3/4 CONDUIT CLIP BG8-12..

Mouse over image to zoom, click to enlarge

  • 812M CDY 1/2 TO 3/4 CONDUIT CLIP BG8-12..
  • 812M CDY 1/2 TO 3/4 CONDUIT CLIP BG8-12..

Description: nVent CADDY Conduit/Pipe Clamp, Snap Close, 1/2 in, 3/4 in Conduit, 25/100 lb, 0.709 to 1.181 in Outside Dia, For Use With: EMT/Rigid Conduit, 9/32 in Plain Hole, Spring Steel/Steel, Caddy® Armor

Manufacturer PN: 812M

UPC:  78285670210

Kendall Electric Inc PN: 23811

Invoice Description:

812M CDY 1/2 TO 3/4 CONDUIT CLIP BG8-12..


SPEC SHEET

▸ See All in Conduit Clamps & Grommets


How Can We Make This Page Better?

nVent CADDY 812M Snap Close Conduit/Pipe Clamp, 1/2 in, 3/4 in Conduit, 25/100 lb Load, 0.709 to 1.181 in OD, Spring Steel/Steel

Log In for Pricing and Availability




Description

The nVent CADDY Snap Close Conduit Clamps (M-Series) are a fast and efficient method to secure conduit branch circuits for electrical installations. The M-Series is designed to provide positional consistency in application by eliminating conduit offset as well as maintain spacing entering electrical boxes. Increase installation efficiency by utilizing our comprehensive conduit range for your next electrical project.
nVent CADDY Conduit/Pipe Clamp, Snap Close, 1/2 in, 3/4 in Conduit, 25/100 lb, 0.709 to 1.181 in Outside Dia, For Use With: EMT/Rigid Conduit, 9/32 in Plain Hole, Spring Steel/Steel, Caddy® Armor

Specifications

 Application Datacom and Low Voltage, Electrical Applications
 Brand Name nVent CADDY
 Conduit Size 1/2 in, 3/4 in
 Finish Caddy® Armor
 Load Capacity 25/100 lb
 Manufacturer Part Number 812M
 Material Spring Steel/Steel
 Specifications 9/32 in Plain Hole
 Standards/Approvals BABA Compliant|cULus Recognized|RoHS Compliant
 Suitable For Use With EMT/Rigid Conduit
 Type Snap Close
 Video Links

Features

▪ May be used for either vertical or horizontal installations
▪ Eliminates need for offset bending conduit
▪ Finger closure, no tools required
▪ Locking design has greater resistance to twisting loads and is stronger than any on the market
▪ Low profile locking tabs and smooth gripping dimples remove the possibility of scrapes
▪ 812M and 16M feature double tabs to center conduit, increase range and holding power and prevent conduit from sliding
