Description: EATON, 80NHG1B-690, Low Voltage, 690 V, 80 A, 45 Hz Frequency, 2.48 in H x 1.57 in W x 5.31 in D Dimensions

Manufacturer PN: 80NHG1B-690

UPC:  05171219326

Kendall Electric Inc PN: 4139018

Invoice Description:

80NHG1B-690 BUSSMANN NH FUSE 80A 690V GG SIZE 1


SPEC SHEET

▸ See All in Fuse Links



EATON 80NHG1B-690 Low Voltage, 690 V, 80 A

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Eaton's Bussmann series low voltage NH fuses range from 2 amps to 1250 amps and provide world class leading performance and reliability. The range is fully compliant with IEC 60269-1, 60269-2, VDE 0636-2 third party approval and DIN 43620. Incorporating a dual indicator design (front and top) NH fuses are able to give both local visual indication and remote (via microswitch) fuse status. Eaton's Bussmann series NH fuses are available in the following operating classes gg, gff and am.
EATON, 80NHG1B-690, Low Voltage, 690 V, 80 A, 45 Hz Frequency, 2.48 in H x 1.57 in W x 5.31 in D Dimensions

Specifications

 Amperage Rating 80 A
 Application For Industrial Facilities & Factories - Facility: Safety and Security Systems, Electrical Assemblies, Panels and EOEMs Applications, Panels and EOEMs, Electrical Assemblies, Panels & EOEM Applications, Electrical Assemblies, Panels & EOEM - Panel Builders, Industrial Facilities & Factories - Facility: Power Distribution and Control, Electrical Assemblies, Panels & EOEM - Control Panels for Machines, Electrical Assemblies, Electrical Assemblies, Panels & EOEM Applications
 Brand Name EATON
 Dimensions 2.48 in H x 1.57 in W x 5.31 in D
 Frequency Rating 45 Hz
 Manufacturer Part Number 80NHG1B-690
 Material Ceramic
 Mounting Type Holder
 PART NUMBER KEYWORDS 80NHG1B-690 ; 80NHG1B690 ; 12876698 ; 051712193269 ; 51712193269 ; 05171219326 ; 5027590490993
 Rated Breaking Capacity 120 kAIC
 Series NHG
 Standards/Approvals IEC 60269-2 ,DIN 43620 ,IEC 60269-1 ,IEC 60269-1 ,DIN 43620 ,IEC 60269-2 ,IEC 60269-2 ,IEC 60269-1 ,DIN 43620 ,IEC 60269-2 ,DIN 43620 ,IEC 60269-1 ,DIN 43620 ,IEC 60269-1 ,IEC 60269-2 ,IEC 60269-2 ,IEC 60269-1 ,DIN 43620,RoHS Compliant,CE Marked,Marquage CE,Conformité RoHS,RoHS-konform,CE-Kennzeichnung,RoHS-compliant,CE-markering,Conforme a RoHS,Con marchio CE,CE-merket,RoHS-kompatibel
 Suitable For Use With Class C/gG/gL Fuse
 Type Low Voltage
 Video Links
 Voltage Rating 690 V

Features

▪ Square body with knife blade contact
