WAGO Corporation
750-1405/040-000 WAGO 51259079 16DI24 VDC 3MS XTR

Mouse over image to zoom, click to enlarge

  • 750-1405/040-000 WAGO 51259079 16DI24 VDC 3MS XTR
  • 750-1405/040-000 WAGO 51259079 16DI24 VDC 3MS XTR
  • 750-1405/040-000 WAGO 51259079 16DI24 VDC 3MS XTR
  • 750-1405/040-000 WAGO 51259079 16DI24 VDC 3MS XTR

Description: WAGO, 750-1405/040-000, Digital Input, 16-Channel, Series: 750, Function: Input, Digital Input, 24 VDC Input, -40 to 70 deg C, 35 mm DIN Rail Mounting, Polycarbonate/Polyamide 6.6, Dark Gray, 3.93 in H x 0.47 in W x 2.71 in D Dimensions

Manufacturer PN: 750-1405/040-000

UPC:  05082146020

Kendall Electric Inc PN: 3975342

Invoice Description:

750-1405/040-000 WAGO 51259079 16DI24 VDC 3MS XTR


SPEC SHEET

▸ See All in PLC Communication Modules


How Can We Make This Page Better?

WAGO 750-1405/040-000 750 16-Channel Digital Input, Input Function, 24 VDC Input Digital Inpu

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

WAGO, 750-1405/040-000, Digital Input, 16-Channel, Series: 750, Function: Input, Digital Input, 24 VDC Input, -40 to 70 deg C, 35 mm DIN Rail Mounting, Polycarbonate/Polyamide 6.6, Dark Gray, 3.93 in H x 0.47 in W x 2.71 in D Dimensions

Specifications

 Application For Marine applications
 Brand Name WAGO
 Color Dark Gray
 Dimensions 3.93 in H x 0.47 in W x 2.71 in D
 Function Input
 Input Rating 24 VDC
 Input Type Digital
 Manufacturer Part Number 750-1405/040-000
 Material Polycarbonate/Polyamide 6.6
 Mounting Type 35 mm DIN Rail
 Series 750
 Standards/Approvals RoHS Compliant
 Temperature Rating -40 to 70 deg C
 Type 16-Channel

Features

▪ An extended temperature range
▪ Greater immunity to impulse voltages and electromagnetic interference
▪ Higher vibration and shock resistance
