Westinghouse Electric

7042100 WESTINGHOUSE STD BASE 3-WIRE SOCKET FN 03072170421

Mouse over image to zoom, click to enlarge

Description: Westinghouse Turn-Knob Socket, 2-Circuit, 250 W Wattage, 250 V AC, E26 Lamp Base, Metal, Brass Plated, 2.56 in H x 2.17 in W x 1.38 in D Dimensions

Manufacturer PN: 7042100

UPC: 03072170421

Kendall Electric Inc PN: 2169237

Invoice Description:

7042100 WESTINGHOUSE STD BASE 3-WIRE SOCKET FN 03072170421

How Can We Make This Page Better?

Westinghouse 7042100 2-Circuit Turn-Knob Socket, 250 W, 250 V AC, E26

Note: Lead times are estimates only

Description Specifications Features Resources

Description

The 2-circuit turn knob socket can be used to replace a worn or broken socket or to build an entirely new light fixture. The socket features two circuits, enabling you to make this a 2-socket lamp by adding another keyless socket (not included) and doubling the light output of one lamp. The turn-knob switch is well suited to floor and table light fixtures, and the brass finish lends a classic look and effectively withstands heat. UL listed and CSA approved for safety, it is rated for 250 W maximum and 250 VAC. The 2-1/2 in H socket has a tapped 1/8-IP bushing and uses medium base bulbs. Thanks to its straight bracket design, installation is easy.

Westinghouse Turn-Knob Socket, 2-Circuit, 250 W Wattage, 250 V AC, E26 Lamp Base, Metal, Brass Plated, 2.56 in H x 2.17 in W x 1.38 in D Dimensions

Specifications

Application	For floor or table fixtures
Brand Name	Westinghouse
Dimensions	2.56 in H x 2.17 in W x 1.38 in D
Finish	Brass Plated
Lamp Base Type	E26
Manufacturer Part Number	7042100
Material	Metal
PART NUMBER KEYWORDS	7042100 ; 8258538 ; 030721704215 ; 30721704215 ; 03072170421 ; 00030721704215
Standards/Approvals	cULus Listed\|CSA Certified\|PROP65: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Type	2-Circuit
Voltage Rating	250 V AC
Wattage	250 W
