Eaton
6709N CWD GRAY CONN.2P-3W 50A 250V 6-50C AUTOGRIP CORD .425" - 1.31"

Mouse over image to zoom, click to enlarge

  • 6709N CWD GRAY CONN.2P-3W 50A 250V 6-50C AUTOGRIP CORD .425" - 1.31"
  • 6709N CWD GRAY CONN.2P-3W 50A 250V 6-50C AUTOGRIP CORD .425" - 1.31"

Description: EATON Arrow Hart™ AutoGrip™ Eaton Wiring Devices Straight Blade Connector, Angled Safety Grip, 250 V AC, 50 A, 2 Pole, 3 Wires, NEMA 6-50R NEMA Rating, Commercial/Industrial Grade, 0.425 to 1.31 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Thermoplastic, Black/Gray, 3.12 in Dia x 5.19 in H Dimensions

Manufacturer PN: 6709N

UPC:  04089302344

Kendall Electric Inc PN: 2049144

Invoice Description:

6709N CWD GRAY CONN.2P-3W 50A 250V 6-50C AUTOGRIP CORD .425" - 1.31"


SPEC SHEET

▸ See All in Straight Blade Connectors


How Can We Make This Page Better?

EATON Arrow Hart™ AutoGrip™ Eaton Wiring Devices 6709N Angled Safety Grip Straight Blade Connector, 250 V AC, 50 A, 2 Poles, 3 Wires, Black/Gray

Log In for Pricing and Availability




Description

Commercial and industrial power plugs and connectors 50 A, 250 VAC NEMA 6-50 2-pole 3-wire. Heavy duty design and construction make Arrow Hart™ power devices ideal for any high amperage industrial or commercial power connectivity application.
EATON Arrow Hart™ AutoGrip™ Eaton Wiring Devices Straight Blade Connector, Angled Safety Grip, 250 V AC, 50 A, 2 Pole, 3 Wires, NEMA 6-50R NEMA Rating, Commercial/Industrial Grade, 0.425 to 1.31 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Thermoplastic, Black/Gray, 3.12 in Dia x 5.19 in H Dimensions

Specifications

 Amperage Rating 50 A
 Brand Name EATON
 Color Black/Gray
 Cord Diameter 0.425 to 1.31 in
 Dimensions 3.12 in Dia x 5.19 in H
 Grade Commercial/Industrial
 Manufacturer Part Number 6709N
 Material Thermoplastic
 NEMA Rating NEMA 6-50R
 Number of Poles 2
 Number of Wires 3
 PART NUMBER KEYWORDS 6709N ; 8201403 ; 040893023441 ; 40893023441 ; 04089302344 ; 00040893023441
 Standards/Approvals cULus Listed,RoHS Compliant
 Temperature Rating -40 to 75 deg C
 Terminal Type Screw
 Type Angled Safety Grip
 Voltage Rating 250 V AC

Features

▪ Unique internal clamp design secures cord during assembly, reducing installation time
▪ Nylon dead front construction resists ingress from contaminants
▪ Tapered cord grip cover reduces cord snags

Resources

 Catalog Page
 Product Data Sheet
