Emerson Electric
5882A GREENLEE MEGOHMMETER, 1KV DIG/ANA LITE ALARM

Mouse over image to zoom, click to enlarge

  • 5882A GREENLEE MEGOHMMETER, 1KV DIG/ANA LITE ALARM
  • 5882A GREENLEE MEGOHMMETER, 1KV DIG/ANA LITE ALARM

Description: Greenlee® Megohmmeter Insulation Tester, Hand Held, 1 kV, 15.3 to 800 Hz Frequency Response, 0 Ohm to 1000 kOhm Resistance, Digital LCD Display, Safety Rating: Cat IV 600 V, (6) 1.5 V DC AA NiMH Batteries Power Source, IP54 Enclosure

Manufacturer PN: 5882A

UPC:  78331007154

Kendall Electric Inc PN: 3878467

Invoice Description:

5882A GREENLEE MEGOHMMETER, 1KV DIG/ANA LITE ALARM


SPEC SHEET

▸ See All in Insulation Testers


How Can We Make This Page Better?

Greenlee® 5882A Hand Held Megohmmeter Insulation Tester, 1 kV, Digital LCD Display, Cat IV 600 V

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Greenlee® Megohmmeter Insulation Tester, Hand Held, 1 kV, 15.3 to 800 Hz Frequency Response, 0 Ohm to 1000 kOhm Resistance, Digital LCD Display, Safety Rating: Cat IV 600 V, (6) 1.5 V DC AA NiMH Batteries Power Source, IP54 Enclosure

Specifications

 Application Cable, Rotary Equipment and Insulation Testing Applications
 Brand Name Greenlee®
 Enclosure IP54
 Frequency Response 15.3 to 800 Hz
 Includes Test Lead Kit of Alligator Clips and Test Probes, Carrying Case with Shoulder Strap, Manual, Battery
 Manufacturer Part Number 5882A
 PART NUMBER KEYWORDS 5882A ; 14309248 ; 783310071549 ; 78331007154 ; 00783310071549
 Power Source (6) 1.5 V DC AA NiMH Batteries
 Resistance Range 0 Ohm to 1000 kOhm
 Standards/Approvals ARRA Compliant|cETLus Listed|CE Certified
 Type Hand Held
 Voltage Rating 1 kV

Features

▪ Calculations (automatic)
▪ Potential Index and Dielectric Absorption Ratios
▪ Measurement tool tests Continuity, Resistance and Frequency Measurements
▪ Programmable Alarms
▪ Hazardous Voltage Alert (Icon) if voltage is greater than 70 V 5.) On Board Timer, +1/- 1 sec
▪ Data hold with 300 Entry Memory
▪ Standby Mode (automatic) saves battery power
▪ Hand Held, Compact Light Weight Form
