Emerson Electric
EDSC11100 APP 1-G 1/2" MAN. MOTOR CONT. FS 78138169714

Mouse over image to zoom, click to enlarge

Description: Appleton® Manual Motor Starter, 1-Gang Feed-Through, Series: Contender™, 120 to 240 V AC/120/240 V DC, 1 hp at 120 to 240 VAC/3/4 hp at 120/240 VDC Motor, 2 Pole, NEMA 3/7C/7D/9E/9F/9G Enclosure, Gray Epoxy Powder Coated Malleable Iron, 3.72 in L x 5.31 in W x 6.81 in H Dimensions

Manufacturer PN: EDSC11100

UPC:  78138169714

Kendall Electric Inc PN: 2186247

Invoice Description:

EDSC11100 APP 1-G 1/2" MAN. MOTOR CONT. FS 78138169714


SPEC SHEET

▸ See All in Hazardous Location Motor Starters


How Can We Make This Page Better?

Appleton® EDSC11100 Contender™ 1-Gang Feed-Through Manual Motor Starter, 2 Poles, NEMA 3/7C/7D/9E/9F/9G Enclosure

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Appleton® explosionproof, dust-ignitionproof, Contender™ Series factory sealed manual motor starters and contactors are available to meet any plant installation requirement. They may be used to install a variety of electrical wiring devices and come complete with covers and dead-end or feed-thru hub arrangements. The Contender™ Series is available with or without a heater. Complete units are ideal for the manual starting of small Vac or Vdc motors in locations made hazardous by the presence of flammable vapors, gases or combustible dust.
Appleton® Manual Motor Starter, 1-Gang Feed-Through, Series: Contender™, 120 to 240 V AC/120/240 V DC, 1 hp at 120 to 240 VAC/3/4 hp at 120/240 VDC Motor, 2 Pole, NEMA 3/7C/7D/9E/9F/9G Enclosure, Gray Epoxy Powder Coated Malleable Iron, 3.72 in L x 5.31 in W x 6.81 in H Dimensions

Specifications

 Application For hazardous locations
 Brand Name Appleton
 Dimensions 3.72 in L x 5.31 in W x 6.81 in H
 Enclosure NEMA 3/7C/7D/9E/9F/9G
 Manufacturer Part Number EDSC11100
 Material Gray Epoxy Powder Coated Malleable Iron
 Motor Power 1 hp at 120 to 240 VAC/3/4 hp at 120/240 VDC
 Number of Poles 2
 PART NUMBER KEYWORDS EDSC11100 ; 8219254 ; 781381697149 ; 78138169714 ; 00781381697149
 Series Contender™
 Standards/Approvals CSA C22.2 #14-M/C22.2 #25/C22.2 #30|cULus E81751/E76550|NEC/CEC Class I Division 1 and 2 Group C D/Class II Division 1 and 2 Group E F G/Class III|UL 508/698/1203
 Type 1-Gang Feed-Through
 Voltage Rating 120 to 240 V AC/120/240 V DC

Features

▪ Constructional feature explosionproof and dust-ignitionproof
▪ Easily readable operator handle with provisions for padlocking in the ON/OFF position
▪ Cast in hubs
▪ Starters can be furnished with one interchangeable heater
▪ Factory sealed
▪ 1/2 in conduit
