Leviton
5369-C LEV 20A/125V 2P3W NYLON CONN BLACK 5-20R

Mouse over image to zoom, click to enlarge

  • 5369-C LEV 20A/125V 2P3W NYLON CONN BLACK 5-20R
  • 5369-C LEV 20A/125V 2P3W NYLON CONN BLACK 5-20R

Description: Leviton®, 5369-C, Straight Blade Connector, Cable Mount Grounding, 125 V AC, 20 A, 2 Pole, 3 Wires, NEMA 5-20R NEMA Rating, Industrial Grade, 0.25 to 0.685 in Diameter Cord, -40 to 60 deg C, Screw Terminal, Nylon, Black/White, 1.49 in Dia x 2.76 in H Dimensions

Manufacturer PN: 5369-C

UPC:  07847779594

Kendall Electric Inc PN: 2396466

Invoice Description:

5369-C LEV 20A/125V 2P3W NYLON CONN BLACK 5-20R


SPEC SHEET

How Can We Make This Page Better?

Leviton® 5369-C Cable Mount Grounding Straight Blade Connector, 125 V AC, 20 A, 2 Poles, 3 Wires, Black/White

Log In for Pricing and Availability




Description

The Leviton® line of straight blade plugs and connectors includes black and White® industrial grade devices that resist impact, corrosion and chemicals and withstand punishing applications. Their innovative interlocking design, rugged nylon flanged inlets and outlets, integrated inlets and outlets with weather resistant covers and hospital grade devices that meet the highest standards for dependable, long term performance. Superior design, construction and ergonomic details provide long lasting performance and reliability in the demanding healthcare environment.
Leviton®, 5369-C, Straight Blade Connector, Cable Mount Grounding, 125 V AC, 20 A, 2 Pole, 3 Wires, NEMA 5-20R NEMA Rating, Industrial Grade, 0.25 to 0.685 in Diameter Cord, -40 to 60 deg C, Screw Terminal, Nylon, Black/White, 1.49 in Dia x 2.76 in H Dimensions

Specifications

 Amperage Rating 20 A
 Brand Name Leviton®
 Color Black/White
 Cord Diameter 0.25 to 0.685 in
 Dimensions 1.49 in Dia x 2.76 in H
 Grade Industrial
 Manufacturer Part Number 5369-C
 Material Nylon
 NEMA Rating NEMA 5-20R
 Number of Poles 2
 Number of Wires 3
 PART NUMBER KEYWORDS 5369-C ; 5369C
 Standards/Approvals ANSI C-73|NOM 057|NEMA WD-1/WD-6|CSA C22.2 No. 42 File No. LR406|UL 498 File No. E13399|Federal Specification WC596|UL94 V-2 Flammability Rating
 Temperature Rating -40 to 60 deg C
 Terminal Type Screw
 Type Cable Mount Grounding
 Video Links
 Voltage Rating 125 V AC

Features

▪ 18 to 10 AWG terminal accommodation
▪ Rugged nylon construction resists impact, sunlight, chemicals and rough use
▪ All contacts are solid 1-piece brass for better conductivity
▪ Triple wipe, heavy duty power contacts set in deep pockets to resist damage
▪ Captive, color coded brass 8 AWG terminal screws
▪ Unique cord clamp accepts wide range of cord sizes (0.245 to 0.7 in), providing secure grip without damaging cord jacket SVT 18/3 to so 14/3 AWG with strain relief insert, up to ST 10/3 AWG when strain relief insert is removed
▪ Power indication devices indicate when power is ON and equipped with green neon bulb rated at 30000 hr (24/7) for 3.5 years
▪ Zinc plated steel assembly screws and solid brass blade and contacts
▪ Thermoplastic back cover, nylon wire module, nylon cord clamp, nylon clamp insert and brass terminal screws
▪ Super tough nylon body
